JVC MX-GA9V User Manual

3-18
Micon board
Block No. [0][3][0][0]
R492 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R493 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R494 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R495 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R496 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R498 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R501 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R502 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R503 QRE141J-303Y C RESISTOR 30k Ω 1/4W J
R504 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R505 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R506 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R507 QRE141J-303Y C RESISTOR 30k Ω 1/4W J
R508 QRE141J-274Y C RESISTOR 270k Ω 1/4W J
R510 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R511 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R512 QRE141J-224Y C RESISTOR 220k Ω 1/4W J
R513 QRE141J-224Y C RESISTOR 220k Ω 1/4W J
R517 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R518 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R519 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R523 QRE141J-822Y C RESISTOR 8.2k
Ω 1/4W J
R524 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R526 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R528 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
R529 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R530 QRE141J-822Y C RESISTOR 8.2k Ω 1/4W J
R531 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R532 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R534 QRE141J-124Y C RESISTOR 120k Ω 1/4W J
R536 QRE141J-113Y C RESISTOR 11k Ω 1/4W J
R537 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R541 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R557 QRE141J-822Y C RESISTOR 8.2k Ω 1/4W J
R558 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R560 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R562 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R563 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R564 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R571 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R572 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R575 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R576 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R577 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R579 QRE141J-184Y C RESISTOR 180k Ω 1/4W J
R580 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R581 QRE141J-224Y C RESISTOR 220k Ω 1/4W J
R582 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R583 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R585 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R586 QRE141J-225Y C RESISTOR 2.2M Ω 1/4W J
R587 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R588 QRE141J-220Y C RESISTOR 22
Ω 1/4W J
R593 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R991 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R992 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R994 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R995 QRE141J-333Y C RESISTOR 33k
Ω 1/4W J
R996 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R997 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R998 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
 R1002 ERX12SJR33E UNF C RESISTOR
R1202 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R1203 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
L001 QQR1277-001Z COIL
L546 QQR1277-001Z COIL
L566 QQR1277-001Z COIL
L567 QQR1277-001Z COIL
L571 QQR1277-001Z COIL
CN11 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN208 WJK0114-002A WIRE
CN209 WJK0071-002A WIRE
CN211 QGB2510K2-11 CONNECTOR B-B (1-11)
CN212 QGB2510K2-10 CONNECTOR B-B (1-10)
CN213 QGB2510K2-04 CONNECTOR B-B (1-4)
CN214 QJK015-071214 SKT WIRE
 Symbol No. Part No. Part Name Description Local
CN218 QGA7901F1-03 CONNECTOR W-B (1-3)
CN219 QGA7901C1-04 CONNECTOR W-B (1-4)
CN220 QGD2504C1-03Z CONNECTOR (1-3)
CN250 QGA7901C1-02 CONNECTOR W-B (1-2)
CN315 QGF1205C1-10 CONNECTOR FFC/FPC (1-10)
CN504 QGF1016F3-15 CONNECTOR FFC/FPC (1-15)
CN661 QGF1016F3-19 CONNECTOR FFC/FPC (1-19)
CN870 QGF1205C1-17 CONNECTOR FFC/FPC (1-17)
CN871 QGF1205C1-17 CONNECTOR FFC/FPC (1-17)
EP250 E409182-001SM GRAND TERMINAL
FT111 QNG0020-001Z FUSE CLIP
FT112 QNG0020-001Z FUSE CLIP
FT131 QNG0020-001Z FUSE CLIP
FT132 QNG0020-001Z FUSE CLIP
FT511 QNG0020-001Z FUSE CLIP
FT512 QNG0020-001Z FUSE CLIP
FT521 QNG0020-001Z FUSE CLIP
FT522 QNG0020-001Z FUSE CLIP
FW401 QUM155-09Z4Z4 FLAT WIRE
FW710 QUM153-09DGZ4 FLAT WIRE
FW714 QUM156-18DGZ4 FLAT WIRE
J411 QNN0420-001 PIN JACK
J426 GP1FA550TZ OPTICAL JACK
Fiber-optic
transmitter unit
J999 QNN0420-001 PIN JACK
JA566 QNN0017-002 PIN JACK
 S500 QSW0812-001 VOLTAGE SWITCH
SP21 VYSA1R3-049 SPACER
SP22 VYSA1R3-049 SPACER
SP23 VYSA1R3-049 SPACER
 Symbol No. Part No. Part Name Description Local
 IC301 KIA78R05PI IC
 IC303 L7808CP IC
 IC304 L7812CP IC
 IC305 L7809CP IC
IC810 MN101C35DEM IC
IC811 BU2092 IC EXPANDER
IC812 BA3835S IC SPI B.P.F.
IC830 KIA7042AP-T IC Regulator
IC901 NJM4580L IC
Dual Operational
Amplifier
IC902 BU9253AS IC LPF & ECHO MIX.
IC951 GP1U271X RM RECIVER Receiver for remote
 Q360 KTC2026/OY/ TRANSISTOR
Q361 2SC2785/FE/-T TRANSISTOR
Q362 2SC2785/FE/-T TRANSISTOR
Q809 2SD1991A/RS/-T TRANSISTOR
Q810 2SD1991A/RS/-T TRANSISTOR
Q811 2SD1991A/RS/-T TRANSISTOR
Q812 2SD1991A/RS/-T TRANSISTOR
Q813 2SD1991A/RS/-T TRANSISTOR
Q816 2SD1991A/RS/-T TRANSISTOR
Q817 2SD1991A/RS/-T TRANSISTOR
Q843 KRA102M-T DIGI TRANSISTOR
Q858 2SD1991A/RS/-T TRANSISTOR
Q875 KRC102M-T DIGI TRANSISTOR
Q877 KRA102M-T DIGI TRANSISTOR
Q878 KRC102M-T DIGI TRANSISTOR
Q879 2SD1991A/RS/-T TRANSISTOR
Q890 2SD1991A/RS/-T TRANSISTOR
Q905 KRC104M-T TRANSISTOR
Q906 KRC104M-T TRANSISTOR
Q907 KRC102M-T DIGI TRANSISTOR
Q908 KRA102M-T DIGI TRANSISTOR
Q918 KRC102M-T DIGI TRANSISTOR
Q919 KRC102M-T DIGI TRANSISTOR
Q920 KRC102M-T DIGI TRANSISTOR
Q940 2SA1175/FE/-T TRANSISTOR
Q941 2SA1175/FE/-T TRANSISTOR
 Symbol No. Part No. Part Name Description Local
