JVC MX-GT91R - Page 64

MX-GT91R
3-7
Item Parts number Parts name Area
A
Parts list (CD changer mechanism)
Q'ty Description
Block No.
M2MM
1 VKS1144-004 CHASSIS 1
2 VKS3698-003 TRAY GUIDE 2
3 VKS5532-003 PULLEY GEAR 2
4 VKB3000-164 BELT 2
5 VKS5505-003 GEAR B 2
6 VKS5506-002 GEAR C 3
7 VKS5507-002 CROSS GEAR U 1
8 VKS5508-002 CROSS GEAR L 1
9 VKS5510-003 SELECT LEVER 1
10 VKH5769-001 S.G.SHAFT 1
11 VKS5511-002 SELECT GEAR 1
12 VKW5155-003 COMP.SPRING 1 FOR SELECT GEAR
13 VKM3846-003 GEAR BRACKET 1
14 VKS5509-002MM CYLINDER GEAR 1
15 MSN5D257A-SA2 D.C.MOTOR ASS'Y 2
16 QYSPSPD2616Z SCREW 2 FOR MOTOR
17 LV40612-001A COMP.SPRING 1
18 VKM3825-00B C.G.BASE ASS'Y 1
19 VKZ3172-00ASS CAM SW. R ASS'Y 1
20 VKZ3173-00ASS CAM SW. L ASS'Y 1
21 QYSPST2606Z SCREW 3 FOR CAM SW.
22 VKS2263-002MM CAM R1 1
23 VKS2264-002MM CAM R2 1
24 VKS2265-002MM CAM GEAR L 1
25 WDL316050MM SLIT WASHER 1 FOR CAM GEAR L
26 WDL316050MM SLIT WASHER 1
27 QYSBSF2608Z T.SCREW 4 FOR C.GEAR BASE
28 VKS3702-00FMM DRIVE UNIT 1
29 VKS2247-004 MECHA HOLDER A 1
30 VKL7767-00D BRACKET ASS'Y 1
31 QYSBSF2606Z SCREW 2 FOR BRACKET
32 VKM3860-00C M.HOLDER B AS'Y 1
33 VKL7802-00D M.HOLDER C AS'Y 1
34 QYSDST2604Z SCREW 2 FOR M.HOLDER C
35 VKL7810-00B LIFTER ASS'Y R 1
36 VKL7811-00B LIFTER ASS'Y L 1
37 VKL7812-00B LIFTER ASS'Y H 1
38 VKL2732-003 LIFTER BASE 1
39 VKM3857-002 LIFTER BRACKET 1
40 QYSDST2604Z SCREW 1
41 WDL266035-2 SLIT WASHER 1
42 QYSBSF2608Z T.SCREW 4
43 VKS5514-002MM LOCK LEVER 3
44 VKY3133-002MM RETURN SPRING 1
45 QYSBSF2608Z T.SCREW 1 FOR RETURN SP.
46 VKY3134-003MM CLICK SPRING 1
47 VKS2252-00L TRAY ASS'Y 3
48 VKS2250-004 TOP BRACKET 1
49 VKS5515-002 S.TRAY STOPPER 1
50 VKW5156-004 TORSION SPRING 1
51 QYSBSF2608Z T.SCREW 3
52 QYSBSF2608Z T.SCREW 2
