MX-GT91R
3-10
Item Parts number Parts name Area
A
Parts list (Cassette mechanism)
Q'ty Description
Block No. M4MM
1 VKS1165-00K MECHA CHASSIS 2
2 VKR4749-003 IDLER PULLEY 2
3 LV42026-001A SHAFT 1 A MECHA
4 VKH5786-003 SHAFT 1 B MECHA
5 VKS2274-002 REEL GEAR 4
6 VKW5286-002 B.T. SPRING 4
7 VKS5559-001 PLAY IDLE GEAR 2
8 VKS5597-00B FR GEAR 2
9 VKW5296-001 EARTH SPRING 2
10 SLC-P1SVM HEAD MOUNT ASSY 1 A MECHA
11 SLC-RP1SVM HEAD MOUNT ASSY 1 B MECHA
12 VKY3149-002 CASSETTE SP. 2
13 VKM3906-003 PLAY SW LEVER 2
14 VKS1166-003 CONTROL CAM 2
15 VKW5279-001 HEAD BASE SP
(
R
)
2
16 VKW5280-001 HEAD BASE SP
(
L
)
2
17 VKS5603-00G MAIN PULLEY ASY 2
18 VKS3785-001MM FR ARM 2
19 VKW5284-002 SWING SPRING 2
20 VKS2278-003 TRIGGER ARM 2
21 VKW5301-001 FR SPRING 2
22 VKW5266-001 ELEVATOR SPRING 2
23 WDL214025 WASHER 2
24 QYSBSF2005Z T.SCREW 2
25 VKS3786-00G CLUTCH ASS'Y 2
26 VKF3205-00B F.WHEEL ASSY
(
R
)
2
27 WDL183425 SLIT WASHER 2
28 VKF3207-00B F.WHEEL ASSY
(
L
)
2
29 WDL173525-6 SLIT WASHER 2
30 VKZ3174-00A DC SOLENOID 2
31 VKB3000-182 CAPSTAN BELT
(
B
)
2
32 MSI-5U2LWA D.C.MOTOR ASS'Y 1
33 VKR4761-001 MOTOR PULLEY 1
34 QYSPSP2604Z SCREW 2
35 VKM3907-001 JOINT BRACKET 1
36 QYSBSF2608Z T.SCREW 6
37 QYSBSF2608Z T.SCREW 5 FOR P.W.B.
