Item
Parts number Parts name Area
Remarks
A
R3327 QRE141J-474Y C RESISTOR 470K 5% 1/4W
R3330 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3331 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3335 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R3336 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R3344 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R3345 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R3347 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R3348 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R3350 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R3351 QRE141J-151Y C RESISTOR 150 5% 1/4W
R3353 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R3354 QRE141J-151Y C RESISTOR 150 5% 1/4W
R3355 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R3359 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3361 QRE141J-393Y C RESISTOR 39K 5% 1/4W
R3362 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R3366 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R3367 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3368 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R3369 QRE141J-101Y C RESISTOR 100 5% 1/4W
R3370 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R3374 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R3376 QRZ9005-100X F RESISTOR 10 1/0W
R3377 QRE141J-470Y C RESISTOR 47 5% 1/4W
R3378 QRE141J-470Y C RESISTOR 47 5% 1/4W
R3379 QRE141J-203Y C RESISTOR 20K 5% 1/4W
R3380 QRE141J-470Y C RESISTOR 47 5% 1/4W
R3381 QRE141J-470Y C RESISTOR 47 5% 1/4W
R3383 QRE141J-471Y C RESISTOR 470 5% 1/4W
SW302 QSW0832-001 LEAF SWITCH
SW303 QSW0832-001 LEAF SWITCH
SW304 QSW0832-001 LEAF SWITCH
SW305 QSW0832-001 LEAF SWITCH
SW306 QSW0859-001 DETECT SWITCH
SW316 QSW0859-001 DETECT SWITCH
VR101 QVP0008-503Z SEMI.V.RESISTOR
VR201 QVP0008-503Z SEMI.V.RESISTOR
VR301 QVP0008-103Z SEMI.V.RESISTOR
Electrical parts list
(Head amplifier & mechanism control board))
Block No. 07
