JVC MX-K10

 MX-K30/MX-K10 FRONT DISPLAY UICOM SELECTION
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
O RA709 NRSA63J-473X MG RESISTOR 47K
O RA710 NRSA63J-473X MG RESISTOR 47K
O RA711 NRSA63J-473X MG RESISTOR 47K
O RA712 NRSA63J-473X MG RESISTOR 47K
O RA713 NRSA63J-473X MG RESISTOR 47K
O RA714 NRSA63J-473X MG RESISTOR 47K
O RA715 NRSA63J-473X MG RESISTOR 47K
O RA716 NRSA63J-473X MG RESISTOR 47K
O RA717 NRSA63J-473X MG RESISTOR 47K
O RA718 NRSA63J-473X MG RESISTOR 47K
O RA719 NRSA63J-473X MG RESISTOR 47K
O RA720 NRSA63J-473X MG RESISTOR 47K
O RA721 NRSA63J-473X MG RESISTOR 47K
O RA722 NRSA63J-473X MG RESISTOR 47K
O RA723 NRSA63J-473X MG RESISTOR 47K
O RA724 NRSA63J-473X MG RESISTOR 47K
O RA725 NRSA63J-473X MG RESISTOR 47K
O RA726 NRSA63J-473X MG RESISTOR 47K
O RA727 NRSA63J-473X MG RESISTOR 47K
O RA728 NRSA63J-473X MG RESISTOR 47K
O RA729 NRSA63J-473X MG RESISTOR 47K
POWER S1001 8EVQ21405P0154 TACT SWITCH EVQ21405R
TAPE S1002 8EVQ21405P0154 TACT SWITCH EVQ21405R
AUX S1003 8EVQ21405P0154 TACT SWITCH EVQ21405R
BAND S1004 8EVQ21405P0154 TACT SWITCH EVQ21405R
SET S1006 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD S1007 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD1 S1008 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD2 S1009 8EVQ21405P0154 TACT SWITCH EVQ21405R
CD3 S1010 8EVQ21405P0154 TACT SWITCH EVQ21405R
EJECT S1011 8EVQ21405P0154 TACT SWITCH EVQ21405R
DISC S1012 8EVQ21405P0154 TACT SWITCH EVQ21405R
DECAB S1013 8EVQ21405P0154 TACT SWITCH EVQ21405R
TM/CK S1014 8EVQ21405P0154 TACT SWITCH EVQ21405R
STOP S1015 8EVQ21405P0154 TACT SWITCH EVQ21405R
TUN- S1016 8EVQ21405P0154 TACT SWITCH EVQ21405R
TUN+ S1017 8EVQ21405P0154 TACT SWITCH EVQ21405R
PRE- S1018 8EVQ21405P0154 TACT SWITCH EVQ21405R
PRE+ S1019 8EVQ21405P0154 TACT SWITCH EVQ21405R
ROCK S1020 8EVQ21405P0154 TACT SWITCH EVQ21405R
CLAS S1021 8EVQ21405P0154 TACT SWITCH EVQ21405R
POP S1022 8EVQ21405P0154 TACT SWITCH EVQ21405R
ABASS S1023 8EVQ21405P0154 TACT SWITCH EVQ21405R
ECO S1024 8EVQ21405P0154 TACT SWITCH EVQ21405R
REC S1025 8EVQ21405P0154 TACT SWITCH EVQ21405R
DUB S1026 8EVQ21405P0154 TACT SWITCH EVQ21405R
CDREC S1027 8EVQ21405P0154 TACT SWITCH EVQ21405R
REPEA S1028 8EVQ21405P0154 TACT SWITCH EVQ21405R
PRO S1029 8EVQ21405P0154 TACT SWITCH EVQ21405R
RON S1030 8EVQ21405P0154 TACT SWITCH EVQ21405R
D.PLAY S1031 8EVQ21405P0154 TACT SWITCH EVQ21405R
PYEON S1032 8EVQ21405P0154 TACT SWITCH EVQ21405R
SEL+ S1033 8EVQ21405P0154 TACT SWITCH EVQ21405R
SEL- S1034 8EVQ21405P0154 TACT SWITCH EVQ21405R
V+/- W1001 804221 JOG SWITCH PVB20FHIN
O X701 29ZTA8.0MP0151 CER. RESONATOR 8.0MHz
O X702 2101012 CRYSTAL 32.768KHz
O --------- 202267010101 HOLDER VFD SPTE THK=0.3mm
O --------- 301773010101 TAPE T=1.0mm EVA
---- --------- 251099G01V THK=1.6mm 94V0 Front Comb. PWB
3-14
