JVC MX-K10

 Electrical parts list (MX-K10/30 CD selection)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
58 O C662 NIL NO MOUNT
59 O C663 NIL NO MOUNT
60 O C664 QETM1HM-105 E CAPACITOR 1uF/50V
61 O C666 NIL NO MOUNT
62 O C667 NIL NO MOUNT
63 O C673 NDC31HJ-101X C CAPACITOR 100P
64 O C674 NIL NO MOUNT
65 O CN601 12S150020 FFC CONNECTOR 15P 1.0mm
66 O CN602 12S600961 CONNECTOR 6P 2.0mm
67 O CN604 12S600961 CONNECTOR 6P 2.0mm
68 O CN606 12S800421 FFC CONNECTOR 8P 1.25mm
69 O CN607 12S220006 FFC CONNECTOR 22P 1.25mm
70 O N603A 12S30039 CONNECTOR 3P 2.0mm
71 O N603B 12S600961 CONNECTOR 6P 2.0mm
72 O D601 11ES2-T4 SI DIODE 1SS133
73 O D602 11ES2-T4 SI DIODE 1SS133
74 O D603 NIL NO MOUNT
75 O D604 NIL NO MOUNT
76 O D605 31N40011 SI DIODE 1N4001
77 O D606 31N40011 SI DIODE 1N4001
78 O D607 31N40011 SI DIODE 1N4001
79 O D608 11ES2-T4 SI DIODE 1SS133
80 O D609 11ES2-T4 SI DIODE 1SS133
81 O D610 11ES2-T4 SI DIODE 1SS133
82 O D611 11ES2-T4 SI DIODE 1SS133
83 O IC601 MN662748RPM IC MN662748RPM
84 O IC611 AN22000A IC AN22000A
85 O IC621 113141 IC BA5936S
86 O JR601 NRSA63J-0R0X MG RESISTOR 0
87 O JR602 NRSA63J-0R0X MG RESISTOR 0
88 O JR603 NRSA63J-0R0X MG RESISTOR 0
89 O JR604 NRSA63J-0R0X MG RESISTOR 0
90 O JR605 NRSA63J-0R0X MG RESISTOR 0
91 O JR606 NRSA63J-0R0X MG RESISTOR 0
O JR607 NRSA63J-0R0X MG RESISTOR 0
92 O JR608 NRSA63J-0R0X MG RESISTOR 0
93 O L601 26100000KM0024 FIXED INDUCTOR 10uH
94 O Q601 2KTA1267GP0008 TRANSISTOR KTA1267GR
95 O Q602 DTC114YSA-T D.TRANSISTOR DTC114YS
96 O Q603 NIL NO MOUNT
97 O Q604 2SA933/RS/-T TRANSISTOR 2SA933S
98 O R601 NRSA63J-272X MG RESISTOR 2.7K
99 O R602 NRSA63J-121X MG RESISTOR 120
100 O R603 NRSA63J-102X MG RESISTOR 1K
101 O R604 NRSA63J-102X MG RESISTOR 1K
102 O R605 NRSA63J-221X MG RESISTOR 220
103 O R606 NIL NO MOUNT
104 O R607 NRSA63J-393X MG RESISTOR 39K
105 O R608 NRSA63J-272X MG RESISTOR 2.7K
106 O R609 NRSA63J-393X MG RESISTOR 39K
107 O R611 NRSA63J-103X MG RESISTOR 10K
108 O R614 NRSA63J-102X MG RESISTOR 1K
109 O R615 NRSA63J-683X MG RESISTOR 68K
110 O R616 NRSA63J-102X MG RESISTOR 1K
111 O R617 NRSA63J-105X MG RESISTOR 1M
112 O R618 NRSA63J-393X MG RESISTOR 39K
113 O R619 NRSA63J-101X MG RESISTOR 100
3-21
