 Electrical parts list (K10 Main Amp Power)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
457 O R515 NRSA63J-103X MG RESISTOR 10K
458 O R516 NRSA63J-682X MG RESISTOR 6.8K
459 O R517 NRSA63J-223X MG RESISTOR 22K
460 O R518 NRSA63J-222X MG RESISTOR 2.2K
461 O R521 NRSA63J-102X MG RESISTOR 1K
462 O R522 NRSA63J-102X MG RESISTOR 1K
463 O R523 NRSA63J-222X MG RESISTOR 2.2K
464 O R901 NRSA63J-472X MG RESISTOR 4.7K
465 ! O R902 RF1010045N0000 FUSI RESISTOR 100 1/4W
466 O R903 NRSA63J-222X MG RESISTOR 2.2K
467 O R904 NRSA63J-101X MG RESISTOR 100
468 O R905 NRSA63J-101X MG RESISTOR 100
469 O R906 NRSA63J-103X MG RESISTOR 10K
470 O R907 NRSA63J-102X MG RESISTOR 1K
471 ! O R908 RF0220045N0000 FUSI RESISTOR 2.2 1/4W(RF)
472 O R909 NRSA63J-473X MG RESISTOR 47K
473 O R910 NRSA63J-223X MG RESISTOR 22K
474 O R911 NRSA63J-332X MG RESISTOR 3.3K
475 O R912 NRSA63J-471X MG RESISTOR 470
476 O R913 NRSA63J-471X MG RESISTOR 470
477 O R914 QRE141J-1R0 C RESISTOR 1
478 O R915 QRE141J-1R0 C RESISTOR 1
479 O R916 QRE141J-1R0 C RESISTOR 1
480 O R917 NRSA63J-102X MG RESISTOR 1K
481 ! O R951 RC3352 RESISTOR 3.3 M 1/2W +/-5%
482 O TB901 201323010101 AC TERMINAL 1P MSC
483 O TB902 201323010101 AC TERMINAL 1P MSC
484 PWB 251131G01V THK1.6mm 94V0 PWB K10 COMB MAIN
3-31
