JVC MX-K30R

 Electrical parts list (K10/30/15 FRONT DISPLY UICOM SELECTION )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
221 O RA719 NRSA63J-473X MG RESISTOR 47K
222 O RA720 NRSA63J-473X MG RESISTOR 47K
223 O RA721 NRSA63J-473X MG RESISTOR 47K
224 O RA722 NRSA63J-473X MG RESISTOR 47K
225 O RA723 NRSA63J-473X MG RESISTOR 47K
226 O RA724 NRSA63J-473X MG RESISTOR 47K
227 O RA725 NRSA63J-473X MG RESISTOR 47K
228 O RA726 NRSA63J-473X MG RESISTOR 47K
229 O RA727 NRSA63J-473X MG RESISTOR 47K
230 O RA728 NRSA63J-473X MG RESISTOR 47K
231 O RA729 NRSA63J-473X MG RESISTOR 47K
232
POWER 1001A 8EVQ21405P0154 TACT SWITCH EVQ21405R
233
TAPE S1002 8EVQ21405P0154 TACT SWITCH EVQ21405R
234 AUX S1003 8EVQ21405P0154 TACT SWITCH EVQ21405R
235 BAND S1004 8EVQ21405P0154 TACT SWITCH EVQ21405R
236 CANCEL S1005 8EVQ21405P0154 TACT SWITCH EVQ21405R
237
SET S1006 8EVQ21405P0154 TACT SWITCH EVQ21405R
238 CD S1007 8EVQ21405P0154 TACT SWITCH EVQ21405R
239 CD1 S1008 8EVQ21405P0154 TACT SWITCH EVQ21405R
240
CD2 S1009 8EVQ21405P0154 TACT SWITCH EVQ21405R
241 CD3 S1010 8EVQ21405P0154 TACT SWITCH EVQ21405R
242 EJECT S1011 8EVQ21405P0154 TACT SWITCH EVQ21405R
243
DISC S1012 8EVQ21405P0154 TACT SWITCH EVQ21405R
244 DECKA/B S1013 8EVQ21405P0154 TACT SWITCH EVQ21405R
245 TIM/CLK S1014 8EVQ21405P0154 TACT SWITCH EVQ21405R
246 STOP S1015 8EVQ21405P0154 TACT SWITCH EVQ21405R
247 TUN- S1016 8EVQ21405P0154 TACT SWITCH EVQ21405R
248 TUN+ S1017 8EVQ21405P0154 TACT SWITCH EVQ21405R
249 PRESET- S1018 8EVQ21405P0154 TACT SWITCH EVQ21405R
250 PRESET+ S1019 8EVQ21405P0154 TACT SWITCH EVQ21405R
251 ROCK S1020 8EVQ21405P0154 TACT SWITCH EVQ21405R
252 CLASSIC S1021 8EVQ21405P0154 TACT SWITCH EVQ21405R
253 POP S1022 8EVQ21405P0154 TACT SWITCH EVQ21405R
254 A.BASS S1023 8EVQ21405P0154 TACT SWITCH EVQ21405R
255 ECO S1024 8EVQ21405P0154 TACT SWITCH EVQ21405R
256
REC S1025 8EVQ21405P0154 TACT SWITCH EVQ21405R
257 DUBBIN S1026 8EVQ21405P0154 TACT SWITCH EVQ21405R
258 CD REC S1027 8EVQ21405P0154 TACT SWITCH EVQ21405R
259
REPEAT S1028 8EVQ21405P0154 TACT SWITCH EVQ21405R
260 Program S1029 8EVQ21405P0154 TACT SWITCH EVQ21405R
261 RONDOM S1030 8EVQ21405P0154 TACT SWITCH EVQ21405R
262 DISPLAY S1031 8EVQ21405P0154 TACT SWITCH EVQ21405R
263 PTY/EON S1032 8EVQ21405P0154 TACT SWITCH EVQ21405R
264 SELECT+ S1033 8EVQ21405P0154 TACT SWITCH EVQ21405R
265 SELECT- S1034 8EVQ21405P0154 TACT SWITCH EVQ21405R
266 VOL+/- W1001 804221 JOG SWITCH PVB20FHIN
267 O X701 29ZTA8.0MP0151 CER. RESONATOR 8.0MHz
268 O X702 2101012 CRYSTAL 32.768KHz
269 O --------- 202267010101 HOLDER VFD SPTE THK=0.3mm
270 O --------- 301773010101 TAPE T=1.0mm EVA
271 ---- --------- 251099G01V THK=1.6mm 94V0 Front Comb. PWB
3-15
