JVC MX-K30R

 Electrical parts list (K10/30/15R Tuner selection)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
1 O C1 QCBB1HK-223 C CAPACITOR 0.022K
2 O C2 QDCB1HJ-150 C CAPACITOR 15PJ
3 O C3 QETM1AM-107 E CAPACITOR 100U/10V
4 O C4 QCBB1HK-473 C CAPACITOR 0.047K
5 O C5 CH1033500KM0190 C CAPACITOR 0.01K
6 O C6 QCBB1HK-473 C CAPACITOR 0.047K
7 O C7 QDCB1HJ-120 C CAPACITOR 12PJ
8 O C8 CH391500JM0130 C CAPACITOR 390PJ
9 O C9 CH1033500KM0190 C CAPACITOR 0.01K
10 O C10 QDCB1HJ-120 C CAPACITOR 12PJ
11 O C11 QETM1AM-107 E CAPACITOR 100U/10V
12 O C12 CH103160NM024B C CAPACITOR 0.01
13 O C13 QCBB1HK-223 C CAPACITOR 0.022K
14 O C14 QDCB1HK-5R6 C CAPACITOR 5.6PK
15 O C15 QDCB1HJ-180 C CAPACITOR 18PJ
16 O C16 QDCB1HK-8R2 C CAPACITOR 8.2PK
17 O C17 QETM1HM-335 E CAPACITOR 3.3U/50V
18 O C18 QDCB1HJ-100 C CAPACITOR 10PJ
19 O C19 QCBB1HK-223 C CAPACITOR 0.022K
20 O C20 QETM1AM-107 E CAPACITOR 100U/10V
21 O C21 QCBB1HK-223 C CAPACITOR 0.022K
22 O C22 QETM1AM-107 E CAPACITOR 100U/10V
23 O C23 QETM1HM-105 E CAPACITOR 1U/50V
24 O C24 QETM1HM-474 E CAPACITOR 0.47U/50V
25 O C25 QETM1HM-105 E CAPACITOR 1U/50V
26 O C26 QDCB1HJ-102 C CAPACITOR 0.001J
27 O C27 QCBB1HK-223 C CAPACITOR 0.022K
28 O C28 QDCB1HJ-122 C CAPACITOR 1200PJ
29 O C29 QETM1HM-475 E CAPACITOR 4.7U/50V
30 O C30 CH1033500KM0190 C CAPACITOR 0.01K
31 O C31 QETM1HM-106 E CAPACITOR 10U/50V
32 O C32 QCBB1HK-104 C CAPACITOR 0.1K
33 O C33 QCBB1HK-472 C CAPACITOR 0.0047K
34 O C34 CH1033500KM0190 C CAPACITOR 0.01K
35 O C35 QFLA2AJ-223 M CAPACITOR 0.022-M
36 O C36 QFLA2AJ-223 M CAPACITOR 0.022-M
37 O C37 QETM1HM-225 E CAPACITOR 2.2U/50V
38 O C38 QETM1HM-225 E CAPACITOR 2.2U/50V
39 O C39 QCBB1HK-222 C CAPACITOR 2200PK
40 O C40 QCBB1HK-222 C CAPACITOR 2200PK
41 O C41 CH1033500KM0190 C CAPACITOR 0.01K
42 O C42 QCBB1HK-223 C CAPACITOR 0.022K
43 O C43 QETM1CM-476 E CAPACITOR 47U/16V
44 O C44 CH1033500KM0190 C CAPACITOR 0.01K
45 O C45 QETM1CM-226 E CAPACITOR 22U/16V
46 O C46 NIL NM
47 O C51 QDCB1HJ-120 C CAPACITOR 12PJ
48 O C52 QDCB1HJ-120 C CAPACITOR 12PJ
49 O C53 QETM1CM-476 E CAPACITOR 47U/16V
50 O C54 CM105500JP0152 AXIAL CER. CAP. 1U-M
51 O C55 QFLA2AJ-392 M CAPACITOR 0.0039-M
52 O C56 QDCB1HJ-102 C CAPACITOR 0.001J
53 O C57 CH1033500KM0190 C CAPACITOR 0.01K
54 O C58 QDGB1HK-102 C CAPACITOR 1000PK
3-16
