JVC MX-K30R

 Electrical parts list (K10/30/15R Tuner selection)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
55 O C59 QETM1AM-107 E CAPACITOR 100U/10V
56 O C60 CH1033500KM0190 C CAPACITOR 0.01K
57 O C61 QCBB1HK-101 C CAPACITOR 100PK
58 O C62 QCBB1HK-101 C CAPACITOR 100PK
59 O C63 QCBB1HK-101 C CAPACITOR 100PK
60 O C64 QDCB1HJ-470 C CAPACITOR 47PJ
61 O C65 CH1033500KM0190 C CAPACITOR 0.01K
62 O C70 QDGB1HK-102 C CAPACITOR 1000PK
63 O C81 QDCB1HJ-221 C CAPACITOR 220PJ
64 O C82 CH1033500KM0190 C CAPACITOR 0.01K
65 O C83 QDCB1HJ-330 C CAPACITOR 33PJ
66 O C84 QDCB1HJ-330 C CAPACITOR 33PJ
67 O C85 QDCB1HJ-221 C CAPACITOR 220PJ
68 O C86 QETM1AM-107 E CAPACITOR 100U/10V
69 O C87 QETM1HM-225 E CAPACITOR 2.2U/50V
70 O C88 QCBB1HK-223 C CAPACITOR 0.022K
71 O C89 QCBB1HK-223 C CAPACITOR 0.022K
72 O C90 QETM1AM-107 E CAPACITOR 100U/10V
73 O C91 CH561500JM0130 C CAPACITOR 560PJ
74 O C92 QDGB1HK-102 C CAPACITOR 1000PK
75 O C93 QDGB1HK-102 C CAPACITOR 1000PK
76 O C104 QETM1HM-105 E CAPACITOR 1U/50V
77 O C204 QETM1HM-105 E CAPACITOR 1U/50V
78 O CF1 29LT10.7MP0151 CER.FILTER 10.7MHz
79 O CF2 29LT10.7MP0151 CER.FILTER 10.7MHz
80 O CF3 29JT10.7MP0151 CER. Discriminator 10.7MHz
81 O CN202 12S13-0027 FFC CONNECTOR 13P 1.25mm
82 O D1 11ES2-T4 SI DIODE 1SS133
83 O D2 11ES2-T4 SI DIODE 1SS133
84 O D3 11ES2-T4 SI DIODE 1SS133
85 O D4 11ES2-T4 SI DIODE 1SS133
86 O D5 11ES2-T4 SI DIODE 1SS133
87 O D6 11ES2-T4 SI DIODE 1SS133
88 O D7 3-3SKV1590-1 Varactor Diode 3KV1590
89 O D50 11ES2-T4 SI DIODE 1SS133
90 O D51 11ES2-T4 SI DIODE 1SS133
91 O D52 11ES2-T4 SI DIODE 1SS133
92 O D53 11ES2-T4 SI DIODE 1SS133
93 O IC1 1-1326-1 IC LA1833
94 O IC2 1-1327-1 IC LC-72136N
95 O IC4 1-1313-1 IC BU1924F
96 O JA302 23-F019-1 Terminal ANT PAL 2P HSP-312V-05
97 O L1 26027000KM0024 INDUCTOR 2.7UH
98 O L2 6-0520-1 MW ANT COIL OH07-864936
99 O L3 6-0518-1 LW ANT COIL LH07-864938
100 O L4 6-0517-1 MW OSC COIL AH07-864937
101 O L5 6-0519-1 LW OSC COIL AH07-864939
102 O L6 26150000KM0024 INDUCTOR 15UH
103 O L8 26101000KM0024 INDUCTOR 100UH
104 O L12 26101000KM0024 INDUCTOR 100UH
105 O L13 26101000KM0024 INDUCTOR 100UH
106 O L50 26221000KM0024 INDUCTOR 220UH
107 O Q1 2KTC3194P0008 TRANSISTOR KTC3194-O
108 O Q2 2KTC3199GP0008 TRANSISTOR KTC3199GR
3-17
