JVC MX-K30R

 Electrical parts list (K10/30/15R Tuner selection)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
109 O Q3 2KTC3199GP0008 TRANSISTOR KTC3199GR
110 O Q4 DTA114YSTP D.TRANSISTOR DTA114YS
111 O Q5 DTC114YSA-T D.TRANSISTOR DTC114YS
112 O Q6 DTC114YSA-T D.TRANSISTOR DTC114YS
113 O Q7 DTA114YSTP D.TRANSISTOR DTA114YS
114 O Q8 DTA114YSTP D.TRANSISTOR DTA114YS
115 O Q9 2KTC3199GP0008 TRANSISTOR KTC3199GR
116 O Q10 2KTA1267GP0008 TRANSISTOR KTA1267GR
117 O Q11 2KTC3195YP0008 TRANSISTOR KTC3195Y
118 O Q12 DTA114YSTP D.TRANSISTOR DTA114YS
119 O R1 QRE141J-220 C RESISTOR 22
120 O R2 QRE141J-102 C RESISTOR 1K
121 O R3 QRE141J-102 C RESISTOR 1K
122 O R4 QRE141J-104 C RESISTOR 100K
123 O R5 QRE141J-152 C RESISTOR 1.5K
124 O R6 QRE141J-472 C RESISTOR 4.7K
125 O R7 QRE141J-472 C RESISTOR 4.7K
126 O R8 QRE141J-471 C RESISTOR 470
127 O R9 QRE141J-331 C RESISTOR 330
128 O R10 QRE141J-333 C RESISTOR 33K
129 O R11 QRE141J-220 C RESISTOR 22
130 O R12 QRE141J-331 C RESISTOR 330
131 O R13 QRE141J-101 C RESISTOR 100
132 O R14 QRE141J-562 C RESISTOR 5.6K
133 O R15 QRE141J-682 C RESISTOR 6.8K
134 O R16 QRE141J-103 C RESISTOR 10K
135 O R17 QRE141J-473 C RESISTOR 47K
136 O R18 QRE141J-101 C RESISTOR 100
137 O R19 QRE141J-332 C RESISTOR 3.3K
138 O R20 QRE141J-472 C RESISTOR 4.7K
139 O R21 QRE141J-183 C RESISTOR 18K
140 O R22 QRE141J-223 C RESISTOR 22K
141 O R23 QRE141J-683 C RESISTOR 68K
142 O R24 QRE141J-153 C RESISTOR 15K
143 O R25 QRE141J-562 C RESISTOR 5.6K
144 O R26 QRE141J-562 C RESISTOR 5.6K
145 O R27 QRE141J-472 C RESISTOR 4.7K
146 O R28 QRE141J-472 C RESISTOR 4.7K
147 O R29 QRE141J-471 C RESISTOR 470
148 O R30 QRE141J-332 C RESISTOR 3.3K
149 O R31 QRE141J-104 C RESISTOR 100K
150 O R32 QRE141J-102 C RESISTOR 1K
151 O R33 QRE141J-330 C RESISTOR 33
152 O R35 QRE141J-103 C RESISTOR 10K
153 O R51 QRE141J-102 C RESISTOR 1K
154 O R52 QRE141J-332 C RESISTOR 3.3K
155 O R53 QRE141J-472 C RESISTOR 4.7K
156 O R54 QRE141J-182 C RESISTOR 1.8K
157 O R55 QRE141J-472 C RESISTOR 4.7K
158 O R56 QRE141J-222 C RESISTOR 2.2K
159 O R57 QRE141J-331 C RESISTOR 330
160 O R58 QRE141J-103 C RESISTOR 10K
161 O R59 QRE141J-102 C RESISTOR 1K
162 O R60 QRE141J-102 C RESISTOR 1K
3-18
