JVC MX-K30R

 Electrical parts list (K10/30/15R Tuner selection)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
163 O R61 QRE141J-102 C RESISTOR 1K
164 O R62 QRE141J-102 C RESISTOR 1K
165 O R63 QRE141J-473 C RESISTOR 47K
166 O R64 QRE141J-473 C RESISTOR 47K
167 O R65 QRE141J-473 C RESISTOR 47K
168 O R66 QRE141J-223 C RESISTOR 22K
169 O R67 QRE141J-223 C RESISTOR 22K
170 O R68 QRE141J-222 C RESISTOR 2.2K
171 O R69 QRE141J-102 C RESISTOR 1K
172 O R70 QRE141J-102 C RESISTOR 1K
173 O R71 QRE141J-102 C RESISTOR 1K
174 O R72 QRE141J-102 C RESISTOR 1K
175 O R73 QRE141J-102 C RESISTOR 1K
176 O R75 QRE141J-474 C RESISTOR 470K
177 O R76 QRE141J-222 C RESISTOR 2.2K
178 O R77 QRE141J-222 C RESISTOR 2.2K
179 O R78 QRE141J-222 C RESISTOR 2.2K
180 O R79 QRE141J-102 C RESISTOR 1K
181 O R80 QRE141J-102 C RESISTOR 1K
182 O T1 29-0154-1 Coil & Filter 450KHz PCFAZHY-AC009
183 O TU1 Z-25-0911-1 FM FRONT END PAD TFFJ4E5
184 O X1 21-0094-2 Crystal 75KHz
185 O X2 21-0150-3 Crystal 4.332MHz
186 O ---------- 202304010101 HOLDER Tuner spte
187 O ---------- 25-1151-G01V THK=1.6mm 94V0 3BAND TU PWB
3-19
