JVC MX-K30R

 Electrical parts list (CD changer mechanism)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
1 O BF601 18A843556N0002 F-BEAD F-B 843556
2 O C601 NCB21CK-334X C CAPACITOR 0.33
3 O C602 NCB31HK-222X C CAPACITOR 2200P
4 O C603 NCB31HK-222X C CAPACITOR 2200P
5 O C605 QETM1AM-227 E CAPACITOR 220uF
6 O C606 NCB31EK-104X C CAPACITOR 0.1
7 O C607 NCB31HK-223X C CAPACITOR 0.022
8 O C608 NCB31EK-104X C CAPACITOR 0.1
9 O C609 NDC31HJ-471X C CAPACITOR 470P
10 O C610 QETM1AM-227 E CAPACITOR 220uF
11 O C611 NCB31EK-104X C CAPACITOR 0.1
12 O C612 NCB31HK-153X C CAPACITOR 0.015
13 O C613 NCB31HK-223X C CAPACITOR 0.022
14 O C614 NCB21CK-154X C CAPACITOR 0.15
15 O C615 NCB21AK-105X C CAPACITOR 1uF
16 O C616 NDC31HJ-150X C CAPACITOR 15P
17 O C617 NDC31HJ-150X C CAPACITOR 15P
18 O C618 QETM1HM-106 E CAPACITOR 10uF
19 O C619 NCB31EK-104X C CAPACITOR 0.1
20 O C620 NCB31EK-104X C CAPACITOR 0.1
21 O C621 QETM1AM-227 E CAPACITOR 220uF
22 O C622 QETM1CM-106 E CAPACITOR 10uF
23 O C623 NIL NO MOUNT
24 O C624 QETM1AM-476 E CAPACITOR 47uF
25 O C626 NCB31EK-104X C CAPACITOR 0.1
26 O C627 NDC31HJ-330X C CAPACITOR 33P
27 O C628 NCB31EK-393X C CAPACITOR 0.039
28 O C629 NCB31EK-473X C CAPACITOR 0.047
29 O C630 NCB31HK-222X C CAPACITOR 2200P
30 O C631 QETM1AM-227 E CAPACITOR 220uF
31 O C632 NCB31EK-473X C CAPACITOR 0.047
32 O C633 NCB31HK-152X C CAPACITOR 1500P
33 O C634 NCB31EK-472X C CAPACITOR 4700P
34 O C635 NCB31CK-104X C CAPACITOR 0.1
35 O C637 NCB31AK-474X C CAPACITOR 0.47
36 O C638 NCB31EK-104X C CAPACITOR 0.1
37 O C639 QETM1AM-107 E CAPACITOR 100uF
38 O C640 NCB31HK-223X C CAPACITOR 0.022
39 O C641 NIL NO MOUNT
40 O C642 NDC31HJ-100X C CAPACITOR 10P
41 O C643 NDC31HJ-101X C CAPACITOR 100P
42 O C644 NCB31HK-223X C CAPACITOR 0.022
43 O C645 NCB31HK-223X C CAPACITOR 0.022
44 O C646 NCB31HK-272X C CAPACITOR 2700P
45 O C647 NCB31HK-272X C CAPACITOR 2700P
46 O C648 NCB31HK-223X C CAPACITOR 0.022
47 O C649 QETM1HM-106 E CAPACITOR 10uF
48 O C650 QETM1AM-227 E CAPACITOR 220uF
49 O C651 NCB31HK-223X C CAPACITOR 0.022
50 O C652 NDC31HJ-391X C CAPACITOR 390P
51 O C653 NDC31HJ-391X C CAPACITOR 390P
52 O C654 NCB31HK-682X C CAPACITOR 0.0068
53 O C655 NCB31EK-472X C CAPACITOR 0.0047
54 O C658 NDC31HJ-391X C CAPACITOR 390P
55 O C659 NDC31HJ-391X C CAPACITOR 390P
56 O C660 NCB31HK-102X C CAPACITOR 1000P
57 O C661 NCB31HK-102X C CAPACITOR 1000P
3-20
