JVC MX-K30R

 Electrical parts list (CD changer mechanism)
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
114 O R620 NIL NO MOUNT
115 O R621 NRSA63J-683X MG RESISTOR 68K
116 O R622 NRSA63J-683X MG RESISTOR 68K
117 O R623 NRSA63J-104X MG RESISTOR 100K
118 O R624 NRSA63J-155X MG RESISTOR 1.5M
119 O R625 NRSA63J-331X MG RESISTOR 330
120 O R626 NRSA63J-564X MG RESISTOR 560K
121 O R627 NIL NO MOUNT
122 O R628 NRSA63J-562X MG RESISTOR 5.6K
123 O R629 NRSA63J-103X MG RESISTOR 10K
124 O R630 NRSA63J-103X MG RESISTOR 10K
125 O R631 NRSA63J-103X MG RESISTOR 10K
126 O R632 NRSA63J-100X MG RESISTOR 10
127 O R633 NRSA63J-100X MG RESISTOR 10
128 O R634 NRSA63J-120X MG RESISTOR 12
129 O R635 NRSA63J-393X MG RESISTOR 39K
130 O R636 NRSA63J-223X MG RESISTOR 22K
131 O R637 NRSA63J-222X MG RESISTOR 2.2K
132 O R638 NRSA63J-332X MG RESISTOR 3.3K
133 O R639 NRSA63J-682X MG RESISTOR 6.8K
134 O R640 NRSA63J-682X MG RESISTOR 6.8K
135 O R641 NRSA63J-0R0X MG RESISTOR 0
136 O R642 NRSA63J-154X MG RESISTOR 150K
137 O R643 NRSA63J-474X MG RESISTOR 470K
138 O R644 NRSA63J-154X MG RESISTOR 150K
139 O R645 NRSA63J-274X MG RESISTOR 270K
140 O R646 NRSA63J-224X MG RESISTOR 220K
141 O R647 NRSA63J-103X MG RESISTOR 10K
142 O R648 NRSA63J-103X MG RESISTOR 10K
143 O R649 NRSA02J-2R2X MG RESISTOR 2.2
144 O R650 NRSA63J-472X MG RESISTOR 4.7K
145 O R651 NRSA63J-273X MG RESISTOR 27K
146 O R652 NRSA63J-122X MG RESISTOR 1.2K
147 O R653 NRSA63J-122X MG RESISTOR 1.2K
148 O R654 NRSA63J-123X MG RESISTOR 12K
149 O R655 NRSA63J-243X MG RESISTOR 24K
150 O R656 NRSA63J-272X MG RESISTOR 2.7K
151 O R657 NRSA63J-392X MG RESISTOR 3.9K
152 O R658 NIL NO MOUNT
153 O R659 NRSA63J-104X MG RESISTOR 100K
154 O R660 NRSA63J-103X MG RESISTOR 10K
155 O R661 NIL NO MOUNT
156 O R662 NRSA63J-562X MG RESISTOR 5.6K
157 O R663 NRSA63J-562X MG RESISTOR 5.6K
158 O R664 NRSA63J-333X MG RESISTOR 33K
159 O R665 NRSA63J-223X MG RESISTOR 22K
160 O R666 NRSA63J-102X MG RESISTOR 1K
161 O R667 NRSA63J-333X MG RESISTOR 33K
162 O R669 NRSA63J-271X MG RESISTOR 270
163 O R670 NRSA63J-394X MG RESISTOR 390K
164 O R671 NRSA63J-822X MG RESISTOR 8.2K
165 O R672 NRSA63J-333X MG RESISTOR 33K
166 O R673 NRSA63J-333X MG RESISTOR 33K
167 O R675 NRSA63J-822X MG RESISTOR 8.2K
168 O X601 2102361 CRYSTAL
16.9344MHz HC49U
169 ------- 251098G01V THK=1.6mm PWB CD PWB 2M
