JVC MX-K30R

 Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
1 MI A QFLA2AJ-822 M CAPACITOR 8200P-M
2 MI B QFLA2AJ-822 M CAPACITOR 8200P-M
3 O C41 NIL NM
4 O C51 NIL NM
5 O C101 NDC31HJ-101X C CAPACITOR 100P
6 O C102 QETM1HM-105 E CAPACITOR 1U/50V
7 O C103 QETM1HM-105 E CAPACITOR 1U/50V
8 O C104 QETM1HM-105 E CAPACITOR 1U/50V
9 O C105 QETM1HM-105 E CAPACITOR 1U/50V
10 O C106 QETM1HM-475 E CAPACITOR 4.7/50V
11 O C107 QETM1HM-475 E CAPACITOR 4.7/50V
12 O C109 QETM1HM-475 E CAPACITOR 4.7/50V
13 O C110 QFV42AJ-823 MF CAPACITOR 0.082-M
14 O C111 QFV42AJ-823 MF CAPACITOR 0.082-M
15 O C112 QFLA2AJ-562 M CAPACITOR 5600P-M
16 O C113 QFV42AJ-124 MF CAPACITOR 0.12-M
17 O C114 QFV42AJ-104 MF CAPACITOR 0.1-M
18 O C115 QETM1AM-107 E CAPACITOR 100/10V
19 O C116 QETM1HM-105 E CAPACITOR 1U/50V
20 O C117 NIL JUMPER WIRE JW
21 O C118 QETM1HM-475 E CAPACITOR 4.7/50V
22 O C119 NDC31HJ-471X C CAPACITOR 470P
23 O C120 NDC31HJ-221X C CAPACITOR 220P
24 O C121 QETM1HM-476 E CAPACITOR 47/50V
25 O C123 NDC31HJ-100X C CAPACITOR 10P
26 O C124 QETM1HM-107 E CAPACITOR 100/50V
27 O C125 QFV42AJ-104 MF CAPACITOR 0.1-M
28 O C126 QFV42AJ-104 MF CAPACITOR 0.1-M
29 O C201 NDC31HJ-101X C CAPACITOR 100P
30 O C202 QETM1HM-105 E CAPACITOR 1U/50V
31 O C203 QETM1HM-105 E CAPACITOR 1U/50V
32 O C204 QETM1HM-105 E CAPACITOR 1U/50V
33 O C205 QETM1HM-105 E CAPACITOR 1U/50V
34 O C206 QETM1HM-475 E CAPACITOR 4.7/50V
35 O C207 QETM1HM-475 E CAPACITOR 4.7/50V
36 O C209 QETM1HM-475 E CAPACITOR 4.7/50V
37 O C210 QFV42AJ-823 MF CAPACITOR 0.082-M
38 O C211 QFV42AJ-823 MF CAPACITOR 0.082-M
39 O C212 QFLA2AJ-562 M CAPACITOR 5600P-M
40 O C213 QFV42AJ-124 MF CAPACITOR 0.12-M
41 O C214 QFV42AJ-104 MF CAPACITOR 0.1-M
42 O C215 QETM1AM-107 E CAPACITOR 100/10V
43 O C216 QETM1HM-105 E CAPACITOR 1U/50V
44 O C217 NIL JUMPER WIRE JW
45 O C218 QETM1HM-475 E CAPACITOR 4.7/50V
46 O C219 NDC31HJ-471X C CAPACITOR 470P
47 O C220 NDC31HJ-221X C CAPACITOR 220P
48 O C221 QETM1HM-476 E CAPACITOR 47/50V
49 O C223 NDC31HJ-100X C CAPACITOR 10P
50 O C224 QETM1HM-107 E CAPACITOR 100/50V
51 O C225 QFV42AJ-104 MF CAPACITOR 0.1-M
52 O C226 QFV42AJ-104 MF CAPACITOR 0.1-M
53 O C301 NCB31HK-102X C CAPACITOR 1000P
54 O C302 NIL NM
55 O C303 QETM1HM-225 E CAPACITOR 2.2U/50V
3-23
