JVC MX-K30R

 Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
111 O C405 QETM1AM-107 E CAPACITOR 100/10V
112 O C407 QETM1HM-475 E CAPACITOR 4.7/50V
113 O C408 QETM1HM-475 E CAPACITOR 4.7/50V
114 O C409 NCB31HK-102X C CAPACITOR 1000P
115 O C410 NCB31HK-332X C CAPACITOR 3300P
116 O C411 QETM1EM-106 E CAPACITOR 10U/25V
117 O C412 NIL NM
118 O C413 CH181500JM0130 C CAPACITOR 180P
119 O C414 NCB31HK-102X C CAPACITOR 1000P
120 O C415 QETM1HM-475 E CAPACITOR 4.7U/50V
121 O C417 NDC31HJ-471X C CAPACITOR 470P
122 O C418 NCB31HK-222X C CAPACITOR 2200P
123 O C501 NCB31HK-681X C CAPACITOR 680P
124 O C502 NCB31HK-681X C CAPACITOR 680P
125 O C503 NDC31HJ-330X C CAPACITOR 33P
126 O C504 QFV42AJ-183 MF CAPACITOR 0.018-M
127 O C505 QETM1AM-107 E CAPACITOR 100/10V
128 O C507 QETM1HM-475 E CAPACITOR 4.7/50V
129 O C508 QETM1HM-475 E CAPACITOR 4.7/50V
130 O C509 NCB31HK-102X C CAPACITOR 1000P
131 O C510 NCB31HK-332X C CAPACITOR 3300P
132 O C511 QETM1EM-106 E CAPACITOR 10U/25V
133 O C512 NIL NM
134 O C513 CH181500JM0130 C CAPACITOR 180P
135 O C514 NCB31HK-102X C CAPACITOR 1000P
136 O C515 QETM1HM-475 E CAPACITOR 4.7U/50V
137 O C517 NDC31HJ-471X C CAPACITOR 470P
138 O C518 NCB31HK-222X C CAPACITOR 2200P
139 O C901 QFLA2AJ-682 M CAPACITOR 0.068-M
140 O C902 QFLA2AJ-682 M CAPACITOR 0.068-M
141 O C903 QFLA2AJ-682 M CAPACITOR 0.068-M
142 O C904 QFLA2AJ-682 M CAPACITOR 0.068-M
143
! O C905 CE33863MSN3 E CAPACITOR 3300/63V
144 ! O C906 CE33863MSN3 E CAPACITOR 3300/63V
145 O C907 NCB21HJ-104X C CAPACITOR 0.1
146 O C908 NCB21HJ-104X C CAPACITOR 0.1
147 O C909 NCB21HJ-104X C CAPACITOR 0.1
148 O C910 NCB21HJ-104X C CAPACITOR 0.1
149
! O C911 CE47825M0 E CAPACITOR 4700/25V
150 O C912 QETL1JM-476 E CAPACITOR 47/63V
151 O C913 QETM1HM-226 E CAPACITOR 22/50V
152 O C914 NCB31HK-103X C CAPACITOR 0.01
153 O C915 QETM1HM-226 E CAPACITOR 22/50V
154 O C916 QETM1EM-106 E CAPACITOR 10/25V
155 O C917 NIL NM
156 O C918 NCB31HK-103X C CAPACITOR 0.01
157 O C919 QETM1AM-107 E CAPACITOR 100/10V
158 O C920 NCB21HJ-104X C CAPACITOR 0.1
159 O C921 QETM1CM-107 E CAPACITOR 100/16V
160 O C922 QETM1EM-106 E CAPACITOR 10/25V
161 O C923 CC22350Z C CAPACITOR 0.022
162 O C981 CH223250ZM0180 C CAPACITOR 0.022
163 O C982 CH223250ZM0180 C CAPACITOR 0.022
164 O C983 CH223250ZM0180 C CAPACITOR 0.022
165 O C984 CH223250ZM0180 C CAPACITOR 0.022
3-25
