JVC MX-K30R

 Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
221 O D982 31N40011 SI DIODE 1N4001
222 O D983 31N40011 SI DIODE 1N4001
223 O D984 31N40011 SI DIODE 1N4001
224 O D985 11ES2-T4 SI DIODE 1SS133
225 O D986 11ES2-T4 SI DIODE 1SS133
226 O D987 11ES2-T4 SI DIODE 1SS133
227 O W1051 12P402341 CONN. ASSY 4P-2.5mm
228 O J1053 23B0112 MINI JACK MSJ-2000
229 O IC102 113241 IC BA1521B
230 O IC103 113231 IC TDA7440D
231
! O IC304 113191 IC STK402-090
232 O IC401 TA8189N IC TA8189
233 O IC402 113221 IC 74HC4094
234 O IC981 110041 IC NJM78L06A
235 O J303 23F0251 SP 4P TERMINAL MSP-103V-04
236 O JA301 23B0931 RCA W/R JACK MSP-242V3
237 O JD75 11ES2-T4 SI DIODE 1SS133
238 O JR1 NRSA63J-0R0X MG RESISTOR 00
239 O JR2 NRSA63J-0R0X MG RESISTOR 00
240 O JR3 NRSA63J-0R0X MG RESISTOR 00
241 O JR4 NRSA63J-0R0X MG RESISTOR 00
242 O JR5 NRSA63J-0R0X MG RESISTOR 00
243 O JR6 NRS181J-0R0X MG RESISTOR 00
244 O JR7 NRSA63J-0R0X MG RESISTOR 00
245 O JR8 NRSA63J-0R0X MG RESISTOR 00
246 O JR9 NRSA63J-0R0X MG RESISTOR 00
247 O JR10 NRSA63J-0R0X MG RESISTOR 00
248 O JR11 NRSA63J-0R0X MG RESISTOR 00
249 O JR12 NRSA63J-0R0X MG RESISTOR 00
250 O JR13 NRSA63J-0R0X MG RESISTOR 00
251 O L101 2600702 Chock Coil 1uH
252 O L102 2601041 Chock Coil 27uH
253 O L1053 18A843556N0002 F-BEAD F-B 843556
254 O L1051 26047000KM0024 INDUCTOR 4.7uH
255 O L1052 26047000KM0024 INDUCTOR 4.7uH
256 O L201 2600702 Chock Coil 1uH
257 O L202 2601041 Chock Coil 27uH
258 O L301 605071 BIAS-COIL 864306
259 O L302 NIL JUMPER WIRE JW
260 O L304 18A843556N0002 F-BEAD F-B 843556
261 O L305 26100000KM0024 INDUCTOR 10uH
262 O L401 NIL JUMPER WIRE JW
263 O L501 NIL JUMPER WIRE JW
264 O Q101 2KTC3199GP0008 TRANSISTOR KTC3199
265 O Q103 2KTC3199GP0008 TRANSISTOR KTC3199
266 O Q104 2KTA1267GP0008 TRANSISTOR KTA1267GR
267 O Q105 2KTC3199GP0008 TRANSISTOR KTC3199
268 O Q201 2KTC3199GP0008 TRANSISTOR KTC3199
269 O Q203 2KTC3199GP0008 TRANSISTOR KTC3199
270 O Q204 2KTA1267GP0008 TRANSISTOR KTA1267GR
271 O Q205 2KTC3199GP0008 TRANSISTOR KTC3199
272 O Q300 KTC3200GR TRANSISTOR KTC3200GR
273 O Q301 KRA107M-T D.TRANSISTOR A107M
274 O Q302 KTC3200GR TRANSISTOR KTC3200
275 O Q303 2KTC3203YP0008 TRANSISTOR KTC3203Y
3-26
