JVC MX-K30R

 Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
276 O Q304 2KTA1267GP0008 TRANSISTOR KTA1267GR
277 O Q305 DTC144ESTP D.TRANSISTOR DTC144ES
278 O Q307 2KTC3199GP0008 TRANSISTOR KTC3199
279 O Q308 DTC144ESTP D.TRANSISTOR DTC144ES
280 O Q309 KTA1273/Y/-T TRANSISTOR KTA1273Y
281 O Q310 2KTC3199GP0008 TRANSISTOR KTC3199
282 O Q311 KTA1273/Y/-T TRANSISTOR KTA1273Y
283 O Q312 2KTC3199GP0008 TRANSISTOR KTC3199
284 O Q313 KTA1273/Y/-T TRANSISTOR KTA1273Y
285 O Q314 DTC114YSA-T D.TRANSISTOR DTC114YS
286 O Q315 2KTC3199GP0008 TRANSISTOR KTC3199
287 O Q316 2KTC3199GP0008 TRANSISTOR KTC3199
288 O Q317 2KTC3199GP0008 TRANSISTOR KTC3199
289 O Q318 DTC114YSA-T D.TRANSISTOR DTC114YS
290 O Q319 2KTA1270YP0008 TRANSISTOR KTA1267Y
291 O Q321 DTC114YSA-T D.TRANSISTOR DTC114YS
292 O Q322 KRA107M-T D.TRANSISTOR A107M
293 O Q323 KRA107M-T D.TRANSISTOR A107M
294 O Q324 KRA107M-T D.TRANSISTOR A107M
295 O Q325 DTC114YSA-T D.TRANSISTOR DTC114YS
296 O Q326 KRA107M-T D.TRANSISTOR KRA107M
297 O Q327 2KTA1267GP0008 TRANSISTOR KTA1267GR
298 O Q331 KTC3200GR TRANSISTOR KTC3200
299 O Q332 2KTA1268GP0008 TRANSISTOR KTA1268
300 O Q333 DTC114YSA-T D.TRANSISTOR DTC114YS
301 O Q334 KRA107M-T D.TRANSISTOR KRA107M
302 O Q335 KRA107M-T D.TRANSISTOR A107M
303 O Q336 2KTC3199GP0008 TRANSISTOR KTC3199
304 O Q337 2KTC3199GP0008 TRANSISTOR KTC3199
305 O Q338 2KTC3199GP0008 TRANSISTOR KTC3199
306 O Q339 DTC114YSA-T D.TRANSISTOR DTC114YS
307 O Q401 2SD2144S/VW/-T TRANSISTOR 2SD2144S
308 O Q402 2SD2144S/VW/-T TRANSISTOR 2SD2144
309 O Q403 2KTC3199GP0008 TRANSISTOR KTC3199
310 O Q404 2KTC3199GP0008 TRANSISTOR KTC3199
311 O Q405 2KTC3199GP0008 TRANSISTOR KTC3199
312 O Q501 2SD2144S/VW/-T TRANSISTOR 2SD2144S
313 O Q502 2SD2144S/VW/-T TRANSISTOR 2SD2144
314 O Q503 2KTC3199GP0008 TRANSISTOR KTC3199
315 O Q504 2KTC3199GP0008 TRANSISTOR KTC3199
316 O Q505 2KTC3199GP0008 TRANSISTOR KTC3199
317 O Q901 2SA934RP0007 TRANSISTOR 2SA934
318 O Q902 NIL NM
319 O Q903 NIL NM
320
! O Q904 2KTB1366Y8 TRANSISTOR KTB1366
321 O Q905 2KTC3199GP0008 TRANSISTOR KTC3199
322 O Q906 2KTC3199GP0008 TRANSISTOR KTC3199
323 ! O Q907 2KTB1366Y8 TRANSISTOR KTB1366
324 O Q908 2KTA1267GP0008 TRANSISTOR KTA1267GR
325 O Q909 KRA107M-T D.TRANSISTOR A107M
326 O Q910 DTC114YSA-T D.TRANSISTOR DTC114YS
327 O Q911 2KTC3199GP0008 TRANSISTOR KTC3199
328 O Q912 DTC114YSA-T D.TRANSISTOR DTC114YS
329 O Q981 DTC114TSA-T D.TRANSISTOR DTC114TS
330 O Q982 DTC114YSA-T D.TRANSISTOR DTC114YS
3-27
