JVC MX-K30R

 Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
331 O Q983 DTC114YSA-T D.TRANSISTOR DTC114YS
332 O R101 NRSA63J-563X MG RESISTOR 56K
333 O R102 NRSA63J-393X MG RESISTOR 39K
334 O R103 NRSA63J-222X MG RESISTOR 2.2K
335 O R104 NRSA63J-222X MG RESISTOR 2.2K
336 O R105 NRSA63J-154X MG RESISTOR 150K
337 O R106 NRSA63J-682X MG RESISTOR 5.6K
338 O R107 NRSA63J-0R0X MG RESISTOR 00
339 O R108 NRSA63J-103X MG RESISTOR 10K
340 O R109 NRSA63J-122X MG RESISTOR 1.2K
341 O R110 NRSA63J-222X MG RESISTOR 2.2K
342 O R111 NRSA63J-222X MG RESISTOR 2.2K
343 O R112 NRSA63J-562X MG RESISTOR 5.6K
344 O R113 NRSA63J-103X MG RESISTOR 10K
345 O R114 NRSA63J-102X MG RESISTOR 1K
346 O R115 NRSA63J-223X MG RESISTOR 22K
347 O R117 NRSA63J-222X MG RESISTOR 2.2K
348 O R118 NRSA63J-472X MG RESISTOR 4.7K
349 O R119 NRSA63J-103X MG RESISTOR 10K
350 O R120 NRSA63J-563X MG RESISTOR 56K
351 O R121 NRSA63J-152X MG RESISTOR 1.5K
352 O R123 NRSA63J-473X MG RESISTOR 47K
353 O R124 NRSA63J-152X MG RESISTOR 1.5K
354 O R125 QRM024K-R22 MP RESISTOR 0.22.2W
355 O R126 QRM024K-R22 MP RESISTOR 0.22.2W
356
! O R127 RF1510045N0000 FUSI RESISTOR 150-1/4W
357 O R128 NRSA63J-220X MG RESISTOR 22
358 O R129 NRSA63J-220X MG RESISTOR 22
359 O R130 NRSA63J-220X MG RESISTOR 22
360 O R131 NRSA63J-103X MG RESISTOR 10K
361 ! O R132 RF3910045N0000 FUSI RESISTOR 390-1/4W
362 ! O R133 RF3910045N0000 FUSI RESISTOR 390-1/4W
363 O R134 NRSA63J-103X MG RESISTOR 10K
364 O R136 NRSA63J-102X MG RESISTOR 1K
365 O R137 NRSA63J-104X MG RESISTOR 100K
366 O R138 NRSA63J-102X MG RESISTOR 1K
367 O R139 QRE141J-103 C RESISTOR 10K
368 O R150 NRSA63J-220X MG RESISTOR 22
369 O R151 NRSA63J-153X MG RESISTOR 15K
370 O R152 NRSA63J-473X MG RESISTOR 47K
371 O R153 NRSA63J-223X MG RESISTOR 22K
372 O R154 NRSA63J-273X MG RESISTOR 27K
373 O R201 NRSA63J-563X MG RESISTOR 56K
374 O R202 NRSA63J-393X MG RESISTOR 39K
375 O R203 NRSA63J-222X MG RESISTOR 2.2K
376 O R204 NRSA63J-222X MG RESISTOR 2.2K
377 O R205 NRSA63J-154X MG RESISTOR 150K
378 O R206 NRSA63J-682X MG RESISTOR 5.6K
379 O R207 NRSA63J-0R0X MG RESISTOR 00
380 O R208 NRSA63J-103X MG RESISTOR 10K
381 O R209 NRSA63J-122X MG RESISTOR 1.2K
382 O R210 NRSA63J-222X MG RESISTOR 2.2K
383 O R211 NRSA63J-222X MG RESISTOR 2.2K
384 O R212 NRSA63J-562X MG RESISTOR 5.6K
385 O R213 NRSA63J-103X MG RESISTOR 10K
3-28
