JVC MX-K30R

 Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
386 O R214 NRSA63J-102X MG RESISTOR 1K
387 O R215 NRSA63J-223X MG RESISTOR 22K
388 O R217 NRSA63J-222X MG RESISTOR 2.2K
389 O R218 NRSA63J-472X MG RESISTOR 4.7K
390 O R219 NRSA63J-103X MG RESISTOR 10K
391 O R220 NRSA63J-563X MG RESISTOR 56K
392 O R221 NRSA63J-152X MG RESISTOR 1.5K
393 O R223 NRSA63J-473X MG RESISTOR 47K
394 O R224 NRSA63J-152X MG RESISTOR 1.5K
395 O R225 QRM024K-R22 MP RESISTOR 0.22-2W
396 O R226 QRM024K-R22 MP RESISTOR 0.22-2W
397
! O R227 RF1510045N0000 FUSI RESISTOR 150-1/4W
398 O R228 NRSA63J-220X MG RESISTOR 22
399 O R229 NRSA63J-220X MG RESISTOR 22
400 O R230 NRSA63J-220X MG RESISTOR 22
401 O R231 NRSA63J-103X MG RESISTOR 10K
402
! O R232 RF3910045N0000 FUSI RESISTOR 390-1/4W
403 ! O R233 RF3910045N0000 FUSI RESISTOR 390-1/4W
404 O R234 NRSA63J-103X MG RESISTOR 10K
405 O R235 NRSA63J-103X MG RESISTOR 10K
406 O R236 NRSA63J-102X MG RESISTOR 1K
407 O R237 NRSA63J-104X MG RESISTOR 100K
408 O R238 NRSA63J-102X MG RESISTOR 1K
409 O R239 NRSA63J-103X MG RESISTOR 10K
410 O R250 NRSA63J-220X MG RESISTOR 22
411 O R251 NRSA63J-153X MG RESISTOR 15K
412 O R253 NRSA63J-223X MG RESISTOR 22K
413 O R254 NRSA63J-273X MG RESISTOR 27K
414 O R301 NRSA63J-102X MG RESISTOR 1K
415 O R303 NRSA63J-102X MG RESISTOR 1K
416 O R304 NRSA63J-331X MG RESISTOR 330
417 O R305 NRSA63J-103X MG RESISTOR 10K
418 O R306 NRSA63J-105X MG RESISTOR 1M
419 O R307 NRSA63J-222X MG RESISTOR 2.2K
420 O R308 NRSA63J-103X MG RESISTOR 10K
421 O R309 NRSA63J-100X MG RESISTOR 10
422 O R310 NRSA02J-390X MG RESISTOR 39
423 O R311 NRSA63J-100X MG RESISTOR 10
424 O R312 NRSA63J-102X MG RESISTOR 1K
425 O R313 NRSA63J-471X MG RESISTOR 470
426 O R314 NRSA63J-474X MG RESISTOR 470K
427 O R315 NRSA63J-222X MG RESISTOR 2.2K
428 O R316 NRSA63J-103X MG RESISTOR 10K
429 O R317 NRSA63J-472X MG RESISTOR 4.7K
430 O R319 NRSA63J-223X MG RESISTOR 22K
431 O R320 NRSA63J-473X MG RESISTOR 47K
432 O R321 NRSA63J-222X MG RESISTOR 2.2K
433 O R322 NRSA63J-222X MG RESISTOR 2.2K
434 O R323 NRSA63J-222X MG RESISTOR 2.2K
435 O R324 NRSA63J-222X MG RESISTOR 2.2K
436 O R325 NRSA63J-222X MG RESISTOR 2.2K
437 O R327 NRSA63J-103X MG RESISTOR 10K
438 O R328 NRSA63J-103X MG RESISTOR 10K
439 O R329 NRSA63J-223X MG RESISTOR 22K
440 O R330 NRSA63J-473X MG RESISTOR 47K
3-29
