JVC MX-K30R

 Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
441 O R331 NRSA63J-332X MG RESISTOR 3.3K
442 O R332 NRSA63J-472X MG RESISTOR 4.7K
443 O R333 NRSA63J-151X MG RESISTOR 150
444 O R334 NRSA63J-332X MG RESISTOR 3.3K
445 O R335 NRSA63J-472X MG RESISTOR 4.7K
446 O R336 NRSA63J-151X MG RESISTOR 150
447 O R337 NRSA63J-332X MG RESISTOR 3.3K
448 O R338 NRSA63J-102X MG RESISTOR 1K
449 O R339 NRSA63J-222X MG RESISTOR 2.2K
450 O R340 NRSA63J-222X MG RESISTOR 2.2K
451 O R341 NRSA63J-222X MG RESISTOR 2.2K
452 O R344 NRSA63J-102X MG RESISTOR 1K
453 O R345 NRSA63J-102X MG RESISTOR 1K
454 O R346 NRSA63J-470X MG RESISTOR 47
455 O R347 NRSA63J-102X MG RESISTOR 1K
456 O R348 NRSA63J-222X MG RESISTOR 2.2K
457 O R349 NRSA63J-221X MG RESISTOR 220
458 O R350 NRSA63J-102X MG RESISTOR 1K
459 O R351 NRSA63J-104X MG RESISTOR 100K
460 O R352 NRSA63J-153X MG RESISTOR 15K
461 O R353 NRSA63J-181X MG RESISTOR 180
462 O R354 NRSA63J-821X MG RESISTOR 820
463 O R355 NRSA63J-330X MG RESISTOR 33
464 O R356 NRSA63J-221X MG RESISTOR 220
465 O R357 NRSA63J-103X MG RESISTOR 10K
466 O R358 NRSA63J-104X MG RESISTOR 100K
467 O R359 NRSA63J-471X MG RESISTOR 470
468 O R360 NRSA63J-222X MG RESISTOR 2.2K
469 O R361 NRSA63J-223X MG RESISTOR 22K
470
! O R362 RF0220045N0000 FUSI RESISTOR 2.2-1/4W
471 O R363 NRSA63J-471X MG RESISTOR 470
472 O R364 NRSA63J-153X MG RESISTOR 15K
473 O R365 NRSA63J-332X MG RESISTOR 3.3K
474 O R366 NRSA63J-682X MG RESISTOR 6.8K
475 O R367 NRSA63J-103X MG RESISTOR 10K
476 O R368 NRSA63J-473X MG RESISTOR 47K
477 O R369 NRSA63J-473X MG RESISTOR 47K
478 O R370 NRSA63J-102X MG RESISTOR 1K
479 O R371 NRSA63J-223X MG RESISTOR 22K
480 O R372 NRSA63J-223X MG RESISTOR 22K
481 O R373 NRSA63J-222X MG RESISTOR 2.2K
482 O R374 NRSA63J-223X MG RESISTOR 22K
483 O R381 NRSA63J-104X MG RESISTOR 100K
484 O R382 NRSA63J-223X MG RESISTOR 22K
485 O R383 NRSA63J-473X MG RESISTOR 47K
486 O R384 NRSA63J-103X MG RESISTOR 10K
487 O R385 NRSA63J-104X MG RESISTOR 100K
488 O R386 QRE141J-100 C RESISTOR 10
489 O R387 NRSA63J-150X MG RESISTOR 15
490 O R388 NRSA63J-222X MG RESISTOR 2.2K
491 O R389 NRSA63J-103X MG RESISTOR 10K
492 O R390 NRSA63J-561X MG RESISTOR 560
493 O R391 NRSA63J-222X MG RESISTOR 2.2K
494 O R401 NRSA63J-104X MG RESISTOR 100K
495 O R402 NRSA63J-682X MG RESISTOR 6.8K
3-30
