JVC MX-K30R

 Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
496 O R404 NRSA63J-101X MG RESISTOR 100
497 O R405 NRSA63J-103X MG RESISTOR 10K
498 O R406 NRSA63J-682X MG RESISTOR 6.8K
499 O R407 NRSA63J-683X MG RESISTOR 68K
500 O R408 NIL NM
501 O R409 NRSA63J-154X MG RESISTOR 150K
502 O R410 NRSA63J-122X MG RESISTOR 1.2K
503 O R412 NRSA63J-182X MG RESISTOR 1.8K
504 O R413 NRSA63J-223X MG RESISTOR 22K
505 O R414 NRSA63J-472X MG RESISTOR 4.7K
506 O R415 NRSA63J-103X MG RESISTOR 10K
507 O R416 NRSA63J-682X MG RESISTOR 6.8K
508 O R417 NRSA63J-223X MG RESISTOR 22K
509 O R418 NRSA63J-222X MG RESISTOR 2.2K
510 O R421 NRSA63J-102X MG RESISTOR 1K
511 O R422 NRSA63J-102X MG RESISTOR 1K
512 O R423 NRSA63J-222X MG RESISTOR 2.2K
513 O R501 NRSA63J-104X MG RESISTOR 100K
514 O R502 NRSA63J-682X MG RESISTOR 6.8K
515 O R504 NRSA63J-101X MG RESISTOR 100
516 O R505 NRSA63J-103X MG RESISTOR 10K
517 O R506 NRSA63J-682X MG RESISTOR 6.8K
518 O R507 NRSA63J-683X MG RESISTOR 68K
519 O R508 NIL NM
520 O R509 NRSA63J-154X MG RESISTOR 150K
521 O R510 NRSA63J-122X MG RESISTOR 1.2K
522 O R512 NRSA63J-182X MG RESISTOR 1.8K
523 O R513 NRSA63J-223X MG RESISTOR 22K
524 O R514 NRSA63J-472X MG RESISTOR 4.7K
525 O R515 NRSA63J-103X MG RESISTOR 10K
526 O R516 NRSA63J-682X MG RESISTOR 6.8K
527 O R517 NRSA63J-223X MG RESISTOR 22K
528 O R518 NRSA63J-222X MG RESISTOR 2.2K
529 O R521 NRSA63J-102X MG RESISTOR 1K
530 O R522 NRSA63J-102X MG RESISTOR 1K
531 O R523 NRSA63J-222X MG RESISTOR 2.2K
532 O R901 NRSA63J-472X MG RESISTOR 4.7K
533
! O R902 RF1010045N0000 FUSI RESISTOR 100 1/4W
534 O R903 NRSA63J-222X MG RESISTOR 2.2K
535 O R904 NRSA63J-101X MG RESISTOR 100
536 O R905 NRSA63J-101X MG RESISTOR 100
537 O R906 NIL NM
538 O R907 NIL NM
539
! O R908 RF0220045N0000 FUSI RESISTOR 2.2 1/4W(RF)
540 O R909 NRSA63J-473X MG RESISTOR 47K
541 O R910 NRSA63J-223X MG RESISTOR 22K
542 O R911 NRSA63J-332X MG RESISTOR 3.3K
543 O R912 NRSA63J-471X MG RESISTOR 470
544 O R913 NRSA63J-471X MG RESISTOR 470
545 O R914 QRE141J-1R0 C RESISTOR 1
546 O R915 QRE141J-1R0 C RESISTOR 1
547 O R916 QRE141J-1R0 C RESISTOR 1
548 O R917 NRSA63J-102X MG RESISTOR 1K
549 O R982 QRE141J-100 C RESISTOR 10
550 O R983 QRE141J-103 C RESISTOR 10K
3-31
