Electrical parts list (K30 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
551 O R984 QRE141J-473 C RESISTOR 47K
552
! O RL981 8RL00131 RELAY DC12V G5PA-1-8
553 ! O T981 21101100800010 P- TRANSFORMER DB-EI28-1296
554 O RY301 8RL00071 RELAY G5PA-2
555 O RXX NIL NM
556 O TB901 201323010101 AC TERMINAL 1P
557 O TB902 201323010101 AC TERMINAL 1P
558 O FH951 201196010101 FUSE HOLDER 1P-5mm
559 O FH952 201196010101 FUSE HOLDER 1P-5mm
560 O SINKA 202323010101 SINK-AMP K30J/E T=1mm
561 O SCREW RT000611B3 SCREW 3xL8mm For sink to Q904
562 O SCREW RT000611B3 SCREW 3xL8mm For sink to Q907
563 MI C132 QFLA2AJ-822 M CAPACITOR 8200P-M
564 MI C232 QFLA2AJ-822 M CAPACITOR 8200P-M
565 MI R155 QRE141J-100 C RESISTOR 10
566 MI R255 QRE141J-100 C RESISTOR 10
567 ---- ---- PWB 251152G01V THK1.6mm 94V0 PWB K30R comb main
3-32
To Next Page
