 Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
1 O C41 NIL NM
2 O C51 NIL NM
3 O C101 NDC31HJ-101X C CAPACITOR 100P
4 O C102 QETM1HM-105 E CAPACITOR 1U/50V
5 O C103 QETM1HM-105 E CAPACITOR 1U/50V
6 O C104 QETM1HM-105 E CAPACITOR 1U/50V
7 O C105 QETM1HM-105 E CAPACITOR 1U/50V
8 O C106 QETM1HM-475 E CAPACITOR 4.7/50V
9 O C107 QETM1HM-475 E CAPACITOR 4.7/50V
10 O C109 QETM1HM-475 E CAPACITOR 4.7/50V
11 O C110 QFV42AJ-823 MF CAPACITOR 0.082-M
12 O C111 QFV42AJ-823 MF CAPACITOR 0.082-M
13 O C112 QFLA2AJ-562 M CAPACITOR 5600P-M
14 O C113 QFV42AJ-124 MF CAPACITOR 0.12-M
15 O C114 QFV42AJ-104 MF CAPACITOR 0.1-M
16 O C115 QETM1AM-107 E CAPACITOR 100/10V
17 O C116 QETM1HM-105 E CAPACITOR 1U/50V
18 O C117 NIL JUMPER WIRE JW
19 O C118 QETM1HM-475 E CAPACITOR 4.7/50V
20 O C119 NDC31HJ-101X C CAPACITOR 100P
21 O C120 NDC31HJ-101X C CAPACITOR 100P
22 O C121 NDC31HJ-330X C CAPACITOR 33P
23 O C122 QETM1HM-476 E CAPACITOR 47U/50V
24 O C123 QETM1HM-226 E CAPACITOR 22U/50V
25 O C124 QETM1HM-106 E CAPACITOR 10U/50V
26 O C125 QFV42AJ-104 MF CAPACITOR 0.1-M
27 O C126 QFV42AJ-104 MF CAPACITOR 0.1-M
28 O C128 CC20350Z C CAPACITOR 0.02
29 O C130 NDC31HJ-471X C CAPACITOR 470P
30 O C201 NDC31HJ-101X C CAPACITOR 100P
31 O C202 QETM1HM-105 E CAPACITOR 1U/50V
32 O C203 QETM1HM-105 E CAPACITOR 1U/50V
33 O C204 QETM1HM-105 E CAPACITOR 1U/50V
34 O C205 QETM1HM-105 E CAPACITOR 1U/50V
35 O C206 QETM1HM-475 E CAPACITOR 4.7/50V
36 O C207 QETM1HM-475 E CAPACITOR 4.7/50V
37 O C209 QETM1HM-475 E CAPACITOR 4.7/50V
38 O C210 QFV42AJ-823 MF CAPACITOR 0.082-M
39 O C211 QFV42AJ-823 MF CAPACITOR 0.082-M
40 O C212 QFLA2AJ-562 M CAPACITOR 5600P-M
41 O C213 QFV42AJ-124 MF CAPACITOR 0.12-M
42 O C214 QFV42AJ-104 MF CAPACITOR 0.1-M
43 O C215 QETM1AM-107 E CAPACITOR 100/10V
44 O C216 QETM1HM-105 E CAPACITOR 1U/50V
45 O C217 NIL JUMPER WIRE JW
46 O C218 QETM1HM-475 E CAPACITOR 4.7/50V
47 O C219 NDC31HJ-101X C CAPACITOR 100P
48 O C220 NDC31HJ-101X C CAPACITOR 100P
49 O C221 NDC31HJ-330X C CAPACITOR 33P
50 O C222 QETM1HM-476 E CAPACITOR 47U/50V
51 O C223 QETM1HM-226 E CAPACITOR 22U/50V
52 O C225 QFV42AJ-104 MF CAPACITOR 0.1-M
53 O C226 QFV42AJ-104 MF CAPACITOR 0.1-M
54 O C230 NDC31HJ-471X C CAPACITOR 470P
3-33
