 Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
55 O C301 NCB31HK-102X C CAPACITOR 1000P
56 O C302 NIL NM
57 O C303 QETM1HM-225 E CAPACITOR 2.2U/50V
58 O C304 NCB31HK-102X C CAPACITOR 1000P
59 O C305 QETM1CM-107 E CAPACITOR 100U/16V
60 O C306 QETM1AM-476 E CAPACITOR 47U/10V
61 O C307 NCB31HK-821X C CAPACITOR 820P
62 O C308 QFV42AJ-153 MF CAPACITOR 0.015-M
63 O C309 NCB31HK-103X C CAPACITOR 0.01U
64 O C310 QETM1CM-107 E CAPACITOR 100U/16V
65 O C311 QFV42AJ-103 MF CAPACITOR 0.01M
66 O C312 QFV42AJ-103 MF CAPACITOR 0.01M
67 O C313 NCB31HK-103X C CAPACITOR 0.01U
68 O C314 NCB31HK-103X C CAPACITOR 0.01U
69 O C315 NCB31HK-103X C CAPACITOR 0.01U
70 O C316 NCB31HK-103X C CAPACITOR 0.01U
71 O C317 QETM1CM-107 E CAPACITOR 100U/16V
72 O C318 QETM1HM-475 E CAPACITOR 4.7U/50V
73 O C319 QETL1CM-108 E CAPACITOR 1000/16V
74 O C320 NDC31HJ-151X C CAPACITOR 150P
75 O C321 NDC31HJ-151X C CAPACITOR 150P
76 O C322 NDC31HJ-151X C CAPACITOR 150P
77 O C323 NCB31HK-103X C CAPACITOR 0.01U
78 O C324 QETM1AM-107 E CAPACITOR 100/10V
79 O C325 QETM1HM-225 E CAPACITOR 2.2/50V
80 O C326 NCB31HK-103X C CAPACITOR 0.01U
81 O C327 QETM1CM-105 E CAPACITOR 1/16V
82 O C328 QETM1CM-476 E CAPACITOR 47/16V
83 O C329 NCB31HK-103X C CAPACITOR 0.01U
84 O C330 NDC31HJ-101X C CAPACITOR 100P
85 O C331 QETM1AM-107 E CAPACITOR 100U/10V
86 O C332 QETM1CM-476 E CAPACITOR 47/16V
87 O C333 NIL NM
88 O C334 QETM1HM-105 E CAPACITOR 1U/50V
89 O C335 QETM1HM-475 E CAPACITOR 4.7/50V
90 O C336 QETM1HM-105 E CAPACITOR 1U/50V
91 O C337 QETM1CM-476 E CAPACITOR 47/16V
92 O C338 NCB31HK-102X C CAPACITOR 1000P
93 O C339 NCB31HK-103X C CAPACITOR 0.01U
94 O C341 NCB31HK-103X C CAPACITOR 0.01U
95 O C342 NCB31HK-103X C CAPACITOR 0.01U
96 O C343 QETL1CM-108 E CAPACITOR 1000U/16V
97 O C344 NCB31HK-122X C CAPACITOR 1200P
98 O C345 NCB31HK-103X C CAPACITOR 0.01U
99 O C346 QETM1CM-106 E CAPACITOR 10/16V
100 O C348 NCB31HK-103X C CAPACITOR 0.01U
101 O C351 QETM1EM-106 E CAPACITOR 10U/25V
102 O C352 QETM1HM-105 E CAPACITOR 1U/50V
103 O C355 QETM1HM-225 E CAPACITOR 2.2U/25V
104 O C371 NCB31HK-103X C CAPACITOR 0.01U
105 O C390 QETM1AM-227 E CAPACITOR 220/10V
106 O C401 NCB31HK-681X C CAPACITOR 680P
107 O C402 NCB31HK-681X C CAPACITOR 680P
108 O C403 NDC31HJ-330X C CAPACITOR 33P
3-34
