 Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
109 O C404 QFV42AJ-183 MF CAPACITOR 0.018-M
110 O C405 QETM1AM-107 E CAPACITOR 100/10V
111 O C407 QETM1HM-475 E CAPACITOR 4.7/50V
112 O C408 QETM1HM-475 E CAPACITOR 4.7/50V
113 O C409 NCB31HK-102X C CAPACITOR 1000P
114 O C410 NCB31HK-332X C CAPACITOR 3300P
115 O C411 QETM1EM-106 E CAPACITOR 10U/25V
116 O C412 NIL NM
117 O C413 CH181500JM0130 C CAPACITOR 180P
118 O C414 NCB31HK-102X C CAPACITOR 1000P
119 O C415 QETM1HM-475 E CAPACITOR 4.7U/50V
120 O C417 NDC31HJ-471X C CAPACITOR 470P
121 O C418 NCB31HK-222X C CAPACITOR 2200P
122 O C501 NCB31HK-681X C CAPACITOR 680P
123 O C502 NCB31HK-681X C CAPACITOR 680P
124 O C503 NDC31HJ-330X C CAPACITOR 33P
125 O C504 QFV42AJ-183 MF CAPACITOR 0.018-M
126 O C505 QETM1AM-107 E CAPACITOR 100/10V
127 O C507 QETM1HM-475 E CAPACITOR 4.7/50V
128 O C508 QETM1HM-475 E CAPACITOR 4.7/50V
129 O C509 NCB31HK-102X C CAPACITOR 1000P
130 O C510 NCB31HK-332X C CAPACITOR 3300P
131 O C511 QETM1EM-106 E CAPACITOR 10U/25V
132 O C512 NIL NM
133 O C513 CH181500JM0130 C CAPACITOR 180P
134 O C514 NCB31HK-102X C CAPACITOR 1000P
135 O C515 QETM1HM-475 E CAPACITOR 4.7U/50V
136 O C517 NDC31HJ-471X C CAPACITOR 470P
137 O C518 NCB31HK-222X C CAPACITOR 2200P
138 O C901 QFLA2AJ-682 M CAPACITOR 0.0068-M
139 O C902 QFLA2AJ-682 M CAPACITOR 0.0068-M
140 O C903 QFLA2AJ-682 M CAPACITOR 0.0068-M
141 O C904 QFLA2AJ-682 M CAPACITOR 0.0068-M
142
! O C905 CE22850M2 E CAPACITOR 2200/50V
143 ! O C906 CE22850M2 E CAPACITOR 2200/50V
144 O C907 NCB21HJ-104X C CAPACITOR 0.1
145 O C908 NCB21HJ-104X C CAPACITOR 0.1
146 O C909 NCB21HJ-104X C CAPACITOR 0.1
147 O C910 NCB21HJ-104X C CAPACITOR 0.1
148
! O C911 CE47825M0 E CAPACITOR 4700/25V
149 O C912 QETL1JM-476 E CAPACITOR 47/63V
150 O C913 QETM1HM-226 E CAPACITOR 22/50V
151 O C914 NCB31HK-103X C CAPACITOR 0.01U
152 O C915 QETM1HM-226 E CAPACITOR 22/50V
153 O C916 QETM1EM-106 E CAPACITOR 10/25V
154 O C917 NIL NM
155 O C918 NCB31HK-103X C CAPACITOR 0.01U
156 O C919 QETM1AM-107 E CAPACITOR 100/10V
157 O C920 NCB21HJ-104X C CAPACITOR 0.1
158 O C921 QETM1CM-107 E CAPACITOR 100/16V
159 O C922 QETM1EM-106 E CAPACITOR 10/25V
160 O C923 CC22350Z C CAPACITOR 0.022
161 O C981 CH223250ZM0180 C CAPACITOR 0.022
162 O C982 CH223250ZM0180 C CAPACITOR 0.022
