 Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
163 O C983 CH223250ZM0180 C CAPACITOR 0.022
164 O C984 CH223250ZM0180 C CAPACITOR 0.022
165 O C985 QETM1EM-477 E CAPACITOR 470U/25V
166 O C986 QETM1HM-335 E CAPACITOR 3.3U/50V
167 O C987 QETM1AM-107 E CAPACITOR 100/10V
168 O C1051 NCB31HK-102X C CAPACITOR 1000P
169 O C1052 NCB31HK-102X C CAPACITOR 1000P
170 O CN101 12S501341 CONNECTOR 5P 2.5mm
171 O CN202 12S110020 FFC CONNECTOR 11P 1.25mm
172 O CN203 12S800421 FFC CONNECTOR 8P 1.25mm
173 O CN305 12S130027 FFC CONNECTOR 13P 1.25mm
174 O CN307 12S30039 CONNECTOR 3P 2.0mm
175 O CN308 12S80024 CONNECTOR 8P 2.0mm
176 O CN701 12S120039 FFC CONNECTOR 12P 1.25mm
177 O CN702 12S210004 FFC CONNECTOR 21P 1.25mm
178 O CN951 12P90047 FLAT CABLE ASSY 9P 2.5mm
179 O CN981 12S40065 FFC CONNECTOR 4P 1.25mm
180 O CN982 12S40065 FFC CONNECTOR 4P 1.25mm
181 O D101 NIL NM
182 O D201 NIL JUMPER WIRE JW
183 O D304 11ES2-T4 SI DIODE 1SS133
184 O D305 NIL JUMPER WIRE JW
185 O D307 UZ5.1BSB Z DIODE MTZJ5.1B
186 O D308 11ES2-T4 SI DIODE 1SS133
187 O D309 11ES2-T4 SI DIODE 1SS133
188 O D310 11ES2-T4 SI DIODE 1SS133
189 O D311 11ES2-T4 SI DIODE 1SS133
190 O D312 11ES2-T4 SI DIODE 1SS133
191 O D313 11ES2-T4 SI DIODE 1SS133
192 O D314 11ES2-T4 SI DIODE 1SS133
193 O D321 11ES2-T4 SI DIODE 1SS133
194 O D322 11ES2-T4 SI DIODE 1SS133
195 O D323 31N40011 SI DIODE 1N4001
196 O D324 11ES2-T4 SI DIODE 1SS133
197 O D328 11ES2-T4 SI DIODE 1SS133
198 O D329 NIL NM
199 O D330 NIL NM
200
! O D901 3RS402M1 BRIDGE DIODE RS402M
201
! O D902 31N40011 SI DIODE 1N4001
202 ! O D903 31N40011 SI DIODE 1N4001
203 ! O D904 31N40011 SI DIODE 1N4001
204 ! O D905 31N40011 SI DIODE 1N4001
205 O D906 31N40011 SI DIODE 1N4001
206 O D907 MTZJ33C-T77 Z DIODE MTZJ33C
207 O D908 MTZ6.2JB Z DIODE MTZJ6.2B
208 O D909 NIL NM
209 O D910 NIL NM
210 O D911 3MTZJ5.6AM0007 Z DIODE MTZJ5.6A
211 O D912 MTZJ12C Z DIODE MTZJ12C
212 O D913 3MTZJ11BM0007 Z DIODE MTZJ11B
213 O D915 MTZJ6.8B Z DIODE MTZJ6.8B
214 O D981 31N40011 SI DIODE 1N4001
215 O D982 31N40011 SI DIODE 1N4001
216 O D983 31N40011 SI DIODE 1N4001
3-36
