 Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
217 O D984 31N40011 SI DIODE 1N4001
218 O D985 11ES2-T4 SI DIODE 1SS133
219 O D986 11ES2-T4 SI DIODE 1SS133
220 O D987 11ES2-T4 SI DIODE 1SS133
221 O FB101 18A00301 FERRITE BEAD CST8.3/3.5/10 3S4
222 MI FB201 18A00301 FERRITE BEAD CST8.3/3.5/10 3S4
223 O FW1051 12P50110 FLAT CABLE ASSY 5P 2.5mm
224 O FW951 12S90023 CONNECTOR 9P 2.5mm
225 O FU981A 201196010101 FUSE HOLDER 1P 5mm
226 O FU981B 201196010101 FUSE HOLDER 1P 5mm
227 O FU952A 201196010101 FUSE HOLDER 1P 5mm
228 O FU952B 201196010101 FUSE HOLDER 1P 5mm
229 O HJ1053 23B0112 MINI JACK MSJ-2000
230
! O IC101 TDA7295 IC TDA7295
231 O IC102 113241 IC BA1521B
232 O IC103 113231 IC TDA7440D
233
! O IC201 TDA7295 IC TDA7295
234 O IC401 TA8189N IC TA8189
235 O IC402 113221 IC 74HC4094
236 O IC981 110041 IC NJM78L06A
237 O J303 23F0251 SP 4P TERMINAL MSP-103V-04
238 O D75 11ES2-T4 SI DIODE 1SS133
239 O JA301 23B0931 RCA W/R JACK MSP-242V3
240 O JR1 NRSA63J-0R0X MG RESISTOR 0
241 O JR2 NRSA63J-0R0X MG RESISTOR 0
242 O JR3 NRSA63J-0R0X MG RESISTOR 0
243 O JR4 NRSA63J-0R0X MG RESISTOR 0
244 O JR5 NRSA63J-0R0X MG RESISTOR 0
245 O JR6 NRS181J-0R0X MG RESISTOR 0
246 O JR7 NRSA63J-0R0X MG RESISTOR 0
247 O JR8 NRSA63J-0R0X MG RESISTOR 0
248 O JR9 NRSA63J-0R0X MG RESISTOR 0
249 O JR10 NRSA63J-0R0X MG RESISTOR 0
250 O JR11 NRSA63J-0R0X MG RESISTOR 0
251 O JR12 NRSA63J-0R0X MG RESISTOR 0
252 O JR13 NRSA63J-0R0X MG RESISTOR 0
253 O JR14 NIL NM
254 O JR15 NRS181J-0R0X MG RESISTOR 0
255 O L101 2600702 CHOCK COIL 1uH
256 O L201 2600702 CHOCK COIL 1uH
257 O L301 605071 BIAS-COIL 864306
258 O L302 NIL JUMPER WIRE JW
259 O L303 NIL JUMPER WIRE JW
260 O L304 18A843556N0002 F-BEAD F-B 843556
261 O L305 26100000KM0024 INDUCTOR 10uH
262 O L401 NIL JUMPER WIRE JW
263 O L501 NIL JUMPER WIRE JW
264 O L1051 26047000KM0024 INDUCTOR 4.7uH
265 O L1052 26047000KM0024 INDUCTOR 4.7uH
266 O L1053 18A843556N0002 F-BEAD F-B 843556
267 O Q101 2KTC3199GP0008 TRANSISTOR KTC3199GR
268 O Q103 2SD2144S/VW/-T TRANSISTOR 2SD2144S
269 MI Q105 2KTC3199GP0008 TRANSISTOR KTC3199GR
270 O Q201 2KTC3199GP0008 TRANSISTOR KTC3199GR
3-37
