JVC MX-K30R User Manual

 Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
271 O Q203 2SD2144S/VW/-T TRANSISTOR 2SD2144S
272 O Q300 KTC3200GR TRANSISTOR KTC3200GR
273 O Q301 KRA107M-T D.TRANSISTOR KRA107M
274 O Q302 KTC3200GR TRANSISTOR KTC3200GR
275 O Q303 2KTC3203YP0008 TRANSISTOR KTC3203Y
276 O Q304 2KTA1267GP0008 TRANSISTOR KTA1267GR
277 O Q305 DTC144ESTP D.TRANSISTOR DTC144ES
278 O Q308 DTC144ESTP D.TRANSISTOR DTC144ES
279 O Q309 KTA1273/Y/-T TRANSISTOR KTA1273Y
280 O Q310 2KTC3199GP0008 TRANSISTOR KTC3199GR
281 O Q311 KTA1273/Y/-T TRANSISTOR KTA1273Y
282 O Q312 2KTC3199GP0008 TRANSISTOR KTC3199GR
283 O Q313 KTA1273/Y/-T TRANSISTOR KTA1273Y
284 O Q314 DTC114YSA-T D.TRANSISTOR DTC114YS
285 O Q315 2KTC3199GP0008 TRANSISTOR KTC3199GR
286 O Q316 2KTC3199GP0008 TRANSISTOR KTC3199GR
287 O Q317 2KTC3199GP0008 TRANSISTOR KTC3199GR
288 O Q318 DTC114YSA-T D.TRANSISTOR DTC114YS
289 O Q319 2KTA1270YP0008 TRANSISTOR KTA1270Y
290 O Q321 DTC114YSA-T D.TRANSISTOR DTC114YS
291 O Q322 KRA107M-T D.TRANSISTOR KRA107M
292 O Q323 KRA107M-T D.TRANSISTOR KRA107M
293 O Q324 KRA107M-T D.TRANSISTOR KRA107M
294 O Q325 DTC114YSA-T D.TRANSISTOR DTC114YS
295 O Q326 KRA107M-T D.TRANSISTOR KRA107M
296 O Q327 2KTA1267GP0008 TRANSISTOR KTA1267GR
297 O Q335 KRA107M-T D.TRANSISTOR KRA107M
298 O Q401 2SD2144S/VW/-T TRANSISTOR 2SD2144S
299 O Q402 2SD2144S/VW/-T TRANSISTOR 2SD2144S
300 O Q403 2KTC3199GP0008 TRANSISTOR KTC3199GR
301 O Q404 2KTC3199GP0008 TRANSISTOR KTC3199GR
302 O Q405 2KTC3199GP0008 TRANSISTOR KTC3199GR
303 O Q501 2SD2144S/VW/-T TRANSISTOR 2SD2144S
304 O Q502 2SD2144S/VW/-T TRANSISTOR 2SD2144S
305 O Q503 2KTC3199GP0008 TRANSISTOR KTC3199GR
306 O Q504 2KTC3199GP0008 TRANSISTOR KTC3199GR
307 O Q505 2KTC3199GP0008 TRANSISTOR KTC3199GR
308 O Q901 2SA934RP0007 TRANSISTOR 2SA934R
309 O Q902 NIL NM
310 O Q903 NIL NM
311
! O Q904 2KTB1366Y8 TRANSISTOR KTB1366Y
312 O Q905 2KTC3199GP0008 TRANSISTOR KTC3199GR
313 O Q906 2KTC3199GP0008 TRANSISTOR KTC3199GR
314
! O Q907 2KTB1366Y8 TRANSISTOR KTB1366Y
315 O Q908 2KTA1267GP0008 TRANSISTOR KTA1267GR
316 O Q909 KRA107M-T D.TRANSISTOR KRA107M
317 O Q910 DTC114YSA-T D.TRANSISTOR DTC114YS
318 O Q911 2KTC3199GP0008 TRANSISTOR KTC3199GR
319 O Q912 DTC114YSA-T D.TRANSISTOR DTC114YS
320 O Q981 DTC114TSA-T D.TRANSISTOR DTC114TS
321 O Q982 DTC114YSA-T D.TRANSISTOR DTC114YS
322 O Q983 DTC114YSA-T D.TRANSISTOR DTC114YS
323 O R101 NRSA63J-563X MG RESISTOR 56K
324 O R102 NRSA63J-393X MG RESISTOR 39K
3-38
