 Electrical parts list (K10 ,K15-MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
325 O R103 NRSA63J-222X MG RESISTOR 2.2K
326 O R104 NRSA63J-222X MG RESISTOR 2.2K
327 O R105 NRSA63J-154X MG RESISTOR 150K
328 O R106 NRSA63J-562X MG RESISTOR 5.6K
329 O R107 NRSA63J-0R0X MG RESISTOR 0
330 O R108 NRSA63J-103X MG RESISTOR 10K
331 O R109 NRSA63J-122X MG RESISTOR 1.2K
332 O R110 NRSA63J-222X MG RESISTOR 2.2K
333 O R111 NRSA63J-222X MG RESISTOR 2.2K
334 O R112 NRSA63J-562X MG RESISTOR 5.6K
335 O R113 NRSA63J-103X MG RESISTOR 10K
336 O R114 NRSA63J-102X MG RESISTOR 1K
337 O R115 NRSA63J-223X MG RESISTOR 22K
338 O R116 NRSA63J-563X MG RESISTOR 56K
339 O R117 NRSA63J-222X MG RESISTOR 2.2K
340 O R118 NRSA63J-472X MG RESISTOR 4.7K
341 O R119 NRSA63J-222X MG RESISTOR 2.2K
342 O R120 NRSA63J-272X MG RESISTOR 2.7K
343 O R121 NRSA63J-563X MG RESISTOR 56K
344 O R122 NRSA63J-122X MG RESISTOR 1.2K
345 O R123 NRSA63J-102X MG RESISTOR 1K
346 O R124 NRSA63J-0R0X MG RESISTOR 0
347 O R125 NRSA63J-102X MG RESISTOR 1K
348 O R128 NRSA63J-220X MG RESISTOR 22
349 O R129 NRSA63J-220X MG RESISTOR 22
350 O R130 NRSA63J-220X MG RESISTOR 22
351 O R131 NRSA63J-103X MG RESISTOR 10K
352 O R138 QRE141J-681 C RESISTOR 680
353 O R150 NRSA63J-220X MG RESISTOR 22
354 O R153 NRSA63J-223X MG RESISTOR 22K
355 O R154 NRSA63J-273X MG RESISTOR 27K
356 MI R155 QRE141J-103 C RESISTOR 10K
357 O R201 NRSA63J-563X MG RESISTOR 56K
358 O R202 NRSA63J-393X MG RESISTOR 39K
359 O R203 NRSA63J-222X MG RESISTOR 2.2K
360 O R204 NRSA63J-222X MG RESISTOR 2.2K
361 O R205 NRSA63J-154X MG RESISTOR 150K
362 O R206 NRSA63J-562X MG RESISTOR 5.6K
363 O R207 NRSA63J-0R0X MG RESISTOR 0
364 O R208 NRSA63J-103X MG RESISTOR 10K
365 O R209 NRSA63J-122X MG RESISTOR 1.2K
366 O R210 NRSA63J-222X MG RESISTOR 2.2K
367 O R211 NRSA63J-222X MG RESISTOR 2.2K
368 O R212 NRSA63J-562X MG RESISTOR 5.6K
369 O R213 NRSA63J-103X MG RESISTOR 10K
370 O R214 NRSA63J-102X MG RESISTOR 1K
371 O R215 NRSA63J-223X MG RESISTOR 22K
372 O R216 NRSA63J-563X MG RESISTOR 56K
373 O R217 NRSA63J-222X MG RESISTOR 2.2K
374 O R218 NRSA63J-472X MG RESISTOR 4.7K
375 O R219 NRSA63J-222X MG RESISTOR 2.2K
376 O R220 NRSA63J-272X MG RESISTOR 2.7K
377 O R221 NRSA63J-563X MG RESISTOR 56K
378 O R222 NRSA63J-122X MG RESISTOR 1.2K
3-39
