 Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
379 O R223 NRSA63J-102X MG RESISTOR 1K
380 O R224 NRSA63J-0R0X MG RESISTOR 0
381 O R225 NRSA63J-102X MG RESISTOR 1K
382 O R226 NRSA63J-223X MG RESISTOR 22K
383 O R227 NRSA63J-223X MG RESISTOR 22K
384 O R228 NRSA63J-220X MG RESISTOR 22
385 O R229 NRSA63J-220X MG RESISTOR 22
386 O R230 NRSA63J-220X MG RESISTOR 22
387 O R231 NRSA63J-103X MG RESISTOR 10K
388 O R232 NIL NM
389 O R238 QRE141J-681 C RESISTOR 680
390 O R250 NRSA63J-220X MG RESISTOR 22
391 O R253 NRSA63J-223X MG RESISTOR 22K
392 O R254 NRSA63J-273X MG RESISTOR 27K
393 O R301 NRSA63J-102X MG RESISTOR 1K
394 O R303 NRSA63J-102X MG RESISTOR 1K
395 O R304 NRSA63J-331X MG RESISTOR 330
396 O R305 NRSA63J-103X MG RESISTOR 10K
397 O R306 NRSA63J-105X MG RESISTOR 1M
398 O R307 NRSA63J-222X MG RESISTOR 2.2K
399 O R308 NRSA63J-103X MG RESISTOR 10K
400 O R309 NRSA63J-100X MG RESISTOR 10
401 O R310 NRSA02J-390X MG RESISTOR 39
402 O R311 NRSA63J-100X MG RESISTOR 10
403 O R312 NRSA63J-102X MG RESISTOR 1K
404 O R313 NRSA63J-471X MG RESISTOR 470
405 O R314 NRSA63J-474X MG RESISTOR 470K
406 O R316 NRSA63J-103X MG RESISTOR 10K
407 O R317 NRSA63J-472X MG RESISTOR 4.7K
408 O R319 NRSA63J-223X MG RESISTOR 22K
409 O R320 NRSA63J-473X MG RESISTOR 47K
410 O R321 NRSA63J-222X MG RESISTOR 2.2K
411 O R322 NRSA63J-222X MG RESISTOR 2.2K
412 O R323 NRSA63J-222X MG RESISTOR 2.2K
413 O R324 NRSA63J-222X MG RESISTOR 2.2K
414 O R325 NRSA63J-222X MG RESISTOR 2.2K
415 O R327 NRSA63J-103X MG RESISTOR 10K
416 O R328 NRSA63J-103X MG RESISTOR 10K
417 O R329 NRSA63J-223X MG RESISTOR 22K
418 O R330 NRSA63J-473X MG RESISTOR 47K
419 O R331 NRSA63J-332X MG RESISTOR 3.3K
420 O R332 NRSA63J-472X MG RESISTOR 4.7K
421 O R333 NRSA63J-151X MG RESISTOR 150
422 O R334 NRSA63J-332X MG RESISTOR 3.3K
423 O R335 NRSA63J-472X MG RESISTOR 4.7K
424 O R336 NRSA63J-151X MG RESISTOR 150
425 O R337 NRSA63J-332X MG RESISTOR 3.3K
426 O R338 NRSA63J-102X MG RESISTOR 1K
427 O R339 NRSA63J-222X MG RESISTOR 2.2K
428 O R340 NRSA63J-222X MG RESISTOR 2.2K
429 O R341 NRSA63J-222X MG RESISTOR 2.2K
430 O R344 NRSA63J-102X MG RESISTOR 1K
431 O R345 NRSA63J-102X MG RESISTOR 1K
432 O R346 NRSA63J-470X MG RESISTOR 47
3-40
