JVC MX-K30R User Manual

 Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
433 O R347 NRSA63J-102X MG RESISTOR 1K
434 O R348 NRSA63J-222X MG RESISTOR 2.2K
435 O R349 NRSA63J-221X MG RESISTOR 220
436 O R350 NRSA63J-102X MG RESISTOR 1K
437 O R351 NRSA63J-104X MG RESISTOR 100K
438 O R352 NRSA63J-153X MG RESISTOR 15K
439 O R353 NRSA63J-181X MG RESISTOR 180
440 O R354 NRSA63J-821X MG RESISTOR 820
441 O R355 NRSA63J-330X MG RESISTOR 33
442 O R356 NRSA63J-221X MG RESISTOR 220
443 O R357 NRSA63J-103X MG RESISTOR 10K
444 O R358 NRSA63J-104X MG RESISTOR 100K
445 O R359 NRSA63J-471X MG RESISTOR 470
446 O R360 NRSA63J-222X MG RESISTOR 2.2K
447 O R361 NRSA63J-223X MG RESISTOR 22K
448
! O R362 RF0220045N0000 FUSI RESISTOR 2.2-1/4W
449 O R363 NRSA63J-471X MG RESISTOR 470
450 O R364 NRSA63J-153X MG RESISTOR 15K
451 O R365 NRSA63J-332X MG RESISTOR 3.3K
452 O R366 NRSA63J-682X MG RESISTOR 6.8K
453 O R367 NRSA63J-103X MG RESISTOR 10K
454 O R368 NRSA63J-473X MG RESISTOR 47K
455 O R369 NRSA63J-473X MG RESISTOR 47K
456 O R370 NRSA63J-102X MG RESISTOR 1K
457 O R371 NRSA63J-223X MG RESISTOR 22K
458 O R372 NRSA63J-223X MG RESISTOR 22K
459 O R373 NRSA63J-222X MG RESISTOR 2.2K
460 O R374 NRSA63J-223X MG RESISTOR 22K
461 O R390 NRSA63J-561X MG RESISTOR 560
462 O R391 NRSA63J-222X MG RESISTOR 2.2K
463 O R401 NRSA63J-104X MG RESISTOR 100K
464 O R402 NRSA63J-682X MG RESISTOR 6.8K
465 O R404 NRSA63J-101X MG RESISTOR 100
466 O R405 NRSA63J-103X MG RESISTOR 10K
467 O R406 NRSA63J-682X MG RESISTOR 6.8K
468 O R407 NRSA63J-683X MG RESISTOR 68K
469 O R408 NIL NM
470 O R409 NRSA63J-154X MG RESISTOR 150K
471 O R410 NRSA63J-122X MG RESISTOR 1.2K
472 O R412 NRSA63J-182X MG RESISTOR 1.8K
473 O R413 NRSA63J-223X MG RESISTOR 22K
474 O R414 NRSA63J-472X MG RESISTOR 4.7K
475 O R415 NRSA63J-103X MG RESISTOR 10K
476 O R416 NRSA63J-682X MG RESISTOR 6.8K
477 O R417 NRSA63J-223X MG RESISTOR 22K
478 O R418 NRSA63J-222X MG RESISTOR 2.2K
479 O R421 NRSA63J-102X MG RESISTOR 1K
480 O R422 NRSA63J-102X MG RESISTOR 1K
481 O R423 NRSA63J-222X MG RESISTOR 2.2K
482 O R501 NRSA63J-104X MG RESISTOR 100K
483 O R502 NRSA63J-682X MG RESISTOR 6.8K
484 O R504 NRSA63J-101X MG RESISTOR 100
485 O R505 NRSA63J-103X MG RESISTOR 10K
486 O R506 NRSA63J-682X MG RESISTOR 6.8K
3-41

JVC MX-K30R Specifications

General

Brand	JVC
Model	MX-K30R
Category	Speaker System
Language	English
