Electrical parts list (K10,K15 -MAIN )
Item !
PWB
TOP
PWB
BOTTOM
Item
Location
Parts number Parts name Remarks Value Area
487 O R507 NRSA63J-683X MG RESISTOR 68K
488 O R508 NIL NM
489 O R509 NRSA63J-154X MG RESISTOR 150K
490 O R510 NRSA63J-122X MG RESISTOR 1.2K
491 O R512 NRSA63J-182X MG RESISTOR 1.8K
492 O R513 NRSA63J-223X MG RESISTOR 22K
493 O R514 NRSA63J-472X MG RESISTOR 4.7K
494 O R515 NRSA63J-103X MG RESISTOR 10K
495 O R516 NRSA63J-682X MG RESISTOR 6.8K
496 O R517 NRSA63J-223X MG RESISTOR 22K
497 O R518 NRSA63J-222X MG RESISTOR 2.2K
498 O R521 NRSA63J-102X MG RESISTOR 1K
499 O R522 NRSA63J-102X MG RESISTOR 1K
500 O R523 NRSA63J-222X MG RESISTOR 2.2K
501 O R901 NRSA63J-472X MG RESISTOR 4.7K
502
! O R902 RF1010045N0000 FUSI RESISTOR 100 1/4W
503 O R903 NRSA63J-222X MG RESISTOR 2.2K
504 O R904 NRSA63J-101X MG RESISTOR 100
505 O R905 NRSA63J-101X MG RESISTOR 100
506 O R906 NIL NM
507 O R907 NIL NM
508
! O R908 RF0220045N0000 FUSI RESISTOR 2.2 1/4W(RF)
509 O R909 NRSA63J-473X MG RESISTOR 47K
510 O R910 NRSA63J-223X MG RESISTOR 22K
511 O R911 NRSA63J-332X MG RESISTOR 3.3K
512 O R912 NRSA63J-471X MG RESISTOR 470
513 O R913 NRSA63J-471X MG RESISTOR 470
514 O R914 QRE141J-1R0 C RESISTOR 1
515 O R915 QRE141J-1R0 C RESISTOR 1
516 O R916 QRE141J-1R0 C RESISTOR 1
517 O R917 NRSA63J-102X MG RESISTOR 1K
518 O R982 QRE141J-100 C RESISTOR 10
519 O R983 QRE141J-103 C RESISTOR 10K
520 O R984 QRE141J-473 C RESISTOR 47K
521
! O RL981 8RL00131 RELAY DC12V G5PA-1-8
522
! O T981 21101100800010 P- TRANSFORMER DB-EI28-1296
523 O TB901 201323010101 AC TERMINAL 1P MSC
524 O TB902 201323010101 AC TERMINAL 1P MSC
525 PWB 251153G01V THK1.6mm 94V0 PWB K10R COMB MAIN
