3-10
Front board
Block No. [0][2][0][0]
Amp. board
Block No. [0][3][0][0]
X801 BI2102361 CRYSTAL 16.9344MHz
XT301 BI2101012 CRYSTAL 32.768KHz
XT302 BI29ZTA8.00P015 C. RESONTOR 8MHz
XXXXX BI251290G01V MAIN PWB
Symbol No.
Part No. Part Name Description Local
IC201 RPM7138-V4 IC BI115291
IC202 S5G5128A |C BI116661
Q201 DTC114TK TRANSISTOR BI2DTC114TKA011
Q202 DTC114TK TRANSISTOR BI2DTC114TKA011
Q205 DTC114TK TRANSISTOR BI2DTC114TKA011
D201 1SS133 FR DIODE BI31SS133M0007
D202 1SS133 FR DIODE BI31SS133M0007
D206 1SS133 FR DIODE BI31SS133M0007
D207 1SS133 FR DIODE BI31SS133M0007
D208 1SS133 FR DIODE BI31SS133M0007
VR201 BI804401 JOG SWITCH RE012307P
L201 BI26100000KM002 INDUCTOR 10UH
L202 BI26010000KM002 INDUCTOR 1uH
L203 BI18A843556N000 FILTER BEAD 843556 TB36
CW201 BI12S1800071 FFC CONNECTOR 18P H 1.25mm
CW202 BI12P402341 CONN. WIRE 4P
CW205 BI12P30232V WIRE 3P
FL201 BI2701941 VFD HNA-14MS09
JK201 BI2301481V EARPHONE JACK PJ-310H
JK202 BI2301471V AUX JACK PJ-310H-03
LD201 B4531E LED BI28B4531EP0110
LD202 SLR-342 LED BI28SLR342VP010
S201 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S202 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S203 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S204 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S205 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S206 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S207 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S208 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S209 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S210 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S211 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S212 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S213 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S214 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S215 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S216 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S217 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S218 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S219 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S220 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S221 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S222 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S223 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S224 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S225 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S226 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S227 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
W201 BI11AT160B0U BLACK WIRE L=160mm IP
W202 BI11AT160B0U BLACK WIRE L=160mm IP
XXXXX BI251292G01V FRONT PWB
XXXXX BI107481010101 LED HOLDER
XXXXX BI202552010101 VFD HOLDER (x2)
XXXXX BI202579010101 SENSOR HOLDER
XXXXX BI301923010101 RUBBER VFD (x2)
XXXXX BI1206341V FLAT CABLE 2P(x2)
XXXXX BI1206351V FLAT CABLE 8P
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
IC601 STK412-030 IC BI115001
Q601 2SC3052F TRANSISTOR BI2SC3052FA013H
Q603 DTA114YK TRANSISTOR BI2DTA114YKA011
Q604 KTB1366Y TRANSISTOR BI2KTB1366Y8V
Q605 2SC3052F TRANSISTOR BI2SC3052FA013H
Q606 DTC114EK TRANSISTOR BI2DTC114EKA011
Q607 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q608 KTB1366Y TRANSISTOR BI2KTB1366Y8V
Q609 2SC3052F TRANSISTOR BI2SC3052FA013H
Q610 2SC3052F TRANSISTOR BI2SC3052FA013H
Q611 DTC323TK TRANSISTOR
BI2DTC323TKA011
7
Q612 DTC323TK TRANSISTOR
BI2DTC323TKA011
7
Q613 KTA1267G TRANSISTOR BI2KTA1267GP000
Q614 KTA1267G TRANSISTOR BI2KTA1267GP000
Q615 2SC3052F TRANSISTOR BI2SC3052FA013H
Q616 2SC3052F TRANSISTOR BI2SC3052FA013H
Q617 2SC3052F TRANSISTOR BI2SC3052FA013H
Q618 2SC3052F TRANSISTOR BI2SC3052FA013H
Q619 DTC114YK TRANSISTOR
BI2DTC114YKA011
7
Q620 DTA114YK TRANSISTOR BI2DTA114YKA011
Q621 DTA114YK TRANSISTOR BI2DTA114YKA011
Q622 DTC323TK TRANSISTOR BI2DTC323TKA011
Q623 DTC323TK TRANSISTOR BI2DTC323TKA011
Q624 DTC114YK TRANSISTOR
BI2DTC114YKA011
7
Q625 DTC114YK TRANSISTOR
BI2DTC114YKA011
7
Q626 DTC114TK TRANSISTOR BI2DTC114TKA011
D601 1N4003 DIODE BI31N4003SEN000
D602 1N4003 DIODE BI31N4003SEN000
D603 1N4003 DIODE BI31N4003SEN000
D605 1N4003 DIODE BI31N4003SEN000
D606 1N4003 DIODE BI31N4003SEN000
D607 UZ12BSC Z DIODE
BI3UZ12BSCM000
0
D609 UZ30BSD Z DIODE
BI3UZ30BSDM000
0
D610 UZ6.2BSB Z DIODE BI3UZ6.2BSBM000
D611 UZ5.6BSB Z DIODE BI3UZ5.6BSBM000
D613 1N4003 DIODE BI31N4003SEN000
D614 RS402M B RECTIFIER BI3RS402M1
D615 G5SBA60 DIODE BI3G5SBA601
D616 UZ15BSC Z DIODE
BI3UZ15BSCM000
0
D617 UZ15BSC Z DIODE
BI3UZ15BSCM000
0
D618 1SS133 FR DIODE BI31SS133M0007
D619 1SS133 FR DIODE BI31SS133M0007
D620 1SS133 FR DIODE BI31SS133M0007
D621 1SS133 FR DIODE BI31SS133M0007
D622 1SS133 FR DIODE BI31SS133M0007
D623 1SS133 FR DIODE BI31SS133M0007
D624 1SS133 FR DIODE BI31SS133M0007
D625 1SS133 FR DIODE BI31SS133M0007
D626 1SS133 FR DIODE BI31SS133M0007
D627 1SS133 FR DIODE BI31SS133M0007
D630 UZ6.2BSB Z DIODE BI3UZ6.2BSBM000
L601 BI2601141 COIL 3.0uH
L602 BI2601141 COIL 3.0uH
CN202 BI12S40047 CONNECTOR 4P V 2.5mm
CN602 BI12S200161 SOCKET CONNECTO 2 PINS SOCKET
CN903 BI12S90025U CONNECTOR 9P H 2.5mm
CW601 BI12S220006 FFC CONNECTOR 22P H 1.25mm
JK601 BI2301271 TERMINAL SP PST- 413-151
RY601 BI8RL00191 RELAY 12V
W901 BI11A050M0 BLACK WIRE 50mm
XXXXX BI251288G01V AMP PWB
XXXXX BI202555010101 HEAT SINK transistor
