Power trans board
Block No. [0][4][0][0]
XXXXX BI202603010101 HLDR THMS
XXXXX BI12P20205U WIRE 2P L=60mm
Symbol No.
Part No. Part Name Description Local
C951 BICT224275M CAPACITOR 0.22UF 275V
CW902 BI12P90062V WIRE
P=2.5mm
L=140mm
XXXXX BI201196010101 FUSE HOLDER CX-NV300
XXXXX BI201323010101 TERMINAL 1P
XXXXX BI251289G01V PWR TRANS PWB
Symbol No.
Part No. Part Name Description Local
