3-10
DVD MPEG board
Block No. [0][4]
R550 CD8022000000600 PULSE GUARD 8022-000000600
R551 CD1221000062020 C RESISTOR 1221-000062020
R552 CD1221681062020 C RESISTOR 1221-681062020
R553 CD1221123062020 C RESISTOR 1221-123062020
RX1 CD1802000000060 OPT. RECEIVER 1802-000000060
L502 CD2721480000000 FERRITE BEAD 2721-480000000
CON501 CD3106120811000 FFC CONNECTOR 3106-120811000
CON502 CD3106120711000 FFC CONNECTOR 3106-120711000
CON503 CD3505020052000 HOUSING 3505-020052000
CON504 CD3505030242000 HOUSING SHIELD 3505-030242000
CP1 CD3102250312000 CONNECTOR 3102-250312000
F501 CD1214033000001 THERMISTOR 1214-033000001
FB501 CD2721601020030 FERRITE BEADS 2721-601020030
FB502 CD2721601020030 FERRITE BEADS 2721-601020030
FB503 CD2721601020030 FERRITE BEADS 2721-601020030
FB504 CD2721601020030 FERRITE BEADS 2721-601020030
FB509 CD1221000062020 C RESISTOR 1221-000062020
FB510 CD1221000062020 C RESISTOR 1221-000062020
HPJ501 CD3202070236000 HP JACK 3202-070236000
MC501 CD1121101081020 C CAPACITOR 1121-101081020 D
MC502 CD1121101081020 C CAPACITOR 1121-101081020 D
MC503 CD1121102082020 C CAPACITOR 1121-102082020 D
MC504 CD1121102082020 C CAPACITOR 1121-102082020 D
MC505 CD1121101081020 C CAPACITOR 1121-101081020 D
MC506 CD1121101081020 C CAPACITOR 1121-101081020 D
MC507 CD1132226063041 E CAPACITOR 1132-226063041 D
MC508 CD1132226063041 E CAPACITOR 1132-226063041 D
MC511 CD1121270081020 C CAPACITOR 1121-270081020 D
MC512 CD1121270081020 C CAPACITOR 1121-270081020 D
MC513 CD1121102082020 C CAPACITOR 1121-102082020 D
MC514 CD1121102082020 C CAPACITOR 1121-102082020 D
MC515 CD1132226063041 E CAPACITOR 1132-226063041 D
MC516 CD1132226063041 E CAPACITOR 1132-226063041 D
MC517 CD1132226063041 E CAPACITOR 1132-226063041 D
MC518 CD1121102082020 C CAPACITOR 1121-102082020 D
MC519 CD1121101081020 C CAPACITOR 1121-101081020 D
MC520 CD1121101081020 C CAPACITOR 1121-101081020 D
MC521 CD1132476053042 E CAPACITOR 1132-476053042 D
MFB501 CD2721601020030 FERRITE BEADS 2721-601020030 D
MFB502 CD2721601020030 FERRITE BEADS 2721-601020030 D
MFB503 CD2721601020030 FERRITE BEADS 2721-601020030 D
MFB504 CD2721601020030 FERRITE BEADS 2721-601020030 D
MFB505 CD2721601020030 FERRITE BEADS 2721-601020030 D
MFB506 CD2721601020030 FERRITE BEADS 2721-601020030 D
MFB507 CD2721601020030 FERRITE BEADS 2721-601020030 D
MFB508 CD2721601020030 FERRITE BEADS 2721-601020030 D
MJK501 CD3202070236000 HP JACK 3202-070236000 D
MJK502 CD3202070236000 HP JACK 3202-070236000 D
MR501 CD1221392062020 C RESISTOR 1221-392062020 D
MR502 CD1221392062020 C RESISTOR 1221-392062020 D
MR503 CD1221511062020 C RESISTOR 1221-511062020 D
MR504 CD1221511062020 C RESISTOR 1221-511062020 D
MR505 CD1221104062020 C RESISTOR 1221-104062020 D
MR506 CD1221104062020 C RESISTOR 1221-104062020 D
MR507 CD1221473062020 C RESISTOR 1221-473062020 D
MR508 CD1221330062020 C RESISTOR 1221-330062020 D
MR509 CD1221473062020 C RESISTOR 1221-473062020 D
MR510 CD1221103062020 C RESISTOR 1221-103062020 D
MR511 CD1221103062020 C RESISTOR 1221-103062020 D
MU501 CD1502004558030 IC 1502-004558030 D
RV501 CD8022000000600 PULSE GUARD 8022-000000600
RV502 CD8022000000600 PULSE GUARD 8022-000000600
SCON1 CD3106120711000 FFC CONNECTOR 3106-120711000
SCON2 CD3101200721000 HEADER 3101-200721000
SCON3 CD3106120811000 FFC CONNECTOR 3106-120811000
SCON4 CD3106120821000 FFC CONNECTOR 3106-120821000
SW501 CD3303020206000 SLIDE SWITCH 3303-020206000
USB501 CD3209040100050 USB JACK 3209-040100050
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
IC1 CD1507004052010 IC 1507-004052010
IC3 CD1507004052010 IC 1507-004052010
U1 CD1507477638000 ESD PROTECTOR 1507-477638000
U2 CD1507477638000 ESD PROTECTOR 1507-477638000
U3 CD1508009984000 IC 1508-009984000
U4 CD1507477638000 ESD PROTECTOR 1507-477638000
U6 CD1509008203020 IC 1509-008203020
U7 CD1513005888020 IC 1513-005888020
U8 CD1511002516010 IC 1511-002516010
U9 CD1508002138000 IC 1508-002138000
U10 CD1511986466010 IC 1511-986466010
U11 CD1508009950000 IC 1508-009950000
U12 CD1508019977000 IC 1508-019977000
U14 CD1424023050020 MOS FET 1424-023050020
U16 CD1508009536010 IC 1508-009536010
U17 CD1510743257000 IC 1510-743257000
U18 CD1424023050020 MOS FET 1424-023050020
UD001 CD1512001117080 IC 1512-001117080
UD004 CD1511002402080 IC 1511-002402080
UD005 CD1511002402080 IC 1511-002402080
UD006 CD1511002402080 IC 1511-002402080
UM203 CD1513006208010 IC 1513-006208010
Q1 CD1422080500020 TRANSISTOR 1422-080500020
Q2 CD1422080500020 TRANSISTOR 1422-080500020
Q3 CD1422080500020 TRANSISTOR 1422-080500020
Q4 CD1424230180010 MOS FET 1424-230180010
Q5 CD1422080500020 TRANSISTOR 1422-080500020
Q6 CD1424230180010 MOS FET 1424-230180010
Q7 CD1422817400010 TRANSISTOR 1422-817400010
Q8 CD1424230180010 MOS FET 1424-230180010
Q16 CD1422080500020 TRANSISTOR 1422-080500020
Q17 CD1424230180010 MOS FET 1424-230180010
Q18 CD1424230180010 MOS FET 1424-230180010
Q19 CD1421211320010 TRANSISTOR 1421-211320010
Q20 CD1421211320010 TRANSISTOR 1421-211320010
Q24 CD1422080500020 TRANSISTOR 1422-080500020
D1 CD1321041480050 DIODE 1321-041480050
D2 CD1321041480050 DIODE 1321-041480050
D3 CD1321041480050 DIODE 1321-041480050
D4 CD1321041480050 DIODE 1321-041480050
D5 CD1321041480050 DIODE 1321-041480050
D6 CD1321041480050 DIODE 1321-041480050
D8 CD1321041480050 DIODE 1321-041480050
D9 CD1321041480050 DIODE 1321-041480050
D10 CD1321041480050 DIODE 1321-041480050
D11 CD1321041480050 DIODE 1321-041480050
D12 CD1321041480050 DIODE 1321-041480050
D14 CD1321041480050 DIODE 1321-041480050
D23 CD1321041480050 DIODE 1321-041480050
C1 CD1121750081020 C CAPACITOR 1121-750081020
C2 CD1121620081020 C CAPACITOR 1121-620081020
C3 CD1121102082020 C CAPACITOR 1121-102082020
C5 CD1121104082020 C CAPACITOR 1121-104082020
C6 CD1121104082020 C CAPACITOR 1121-104082020
C7 CD1121750081020 C CAPACITOR 1121-750081020
C8 CD1121102082020 C CAPACITOR 1121-102082020
C9 CD1121104082020 C CAPACITOR 1121-104082020
C10 CD1121104082020 C CAPACITOR 1121-104082020
C11 CD1121620081020 C CAPACITOR 1121-620081020
C13 CD1121330081020 C CAPACITOR 1121-330081020
C14 CD1121750081020 C CAPACITOR 1121-750081020
C15 CD1121620081020 C CAPACITOR 1121-620081020
C17 CD1121104082020 C CAPACITOR 1121-104082020
C18 CD1121104082020 C CAPACITOR 1121-104082020
C19 CD1121102082020 C CAPACITOR 1121-102082020
C20 CD1121104082020 C CAPACITOR 1121-104082020
C21 CD1121104082020 C CAPACITOR 1121-104082020
C22 CD1121105052020 C CAPACITOR 1121-105052020
C23 CD1121104082020 C CAPACITOR 1121-104082020
C24 CD1121240081021 C CAPACITOR 1121-240081021
C25 CD1121104082020 C CAPACITOR 1121-104082020
