3-18
SMPS board
Block No. [0][6]
Symbol No.
Part No. Part Name Description Local
U1 CD1512001216020 IC 1512-001216020
U2 CD1508031565000 IC 1508-031565000
U3 CD1415008170000 PHOTO COUPLER 1415-008170000
U4 CD1415008170000 PHOTO COUPLER 1415-008170000
U5 CD1415008170000 PHOTO COUPLER 1415-008170000
U6 CD1512000431020 IC 1512-000431020
U7 CD1512000431020 IC 1512-000431020
U8 CD1512000431020 IC 1512-000431020 D
D1 CD1314000100000 RECTIFIER 1314-000100000
D2 CD1311001570000 DIODE 1311-001570000
D3 CD1311140070020 DIODE 1311-140070020
D4 CD1311001040030 DIODE 1311-001040030
D5 CD1311141480010 DIODE 1311-141480010
D6 CD1311001040030 DIODE 1311-001040030
D7 CD1311008300000 DIODE 1311-008300000
D8 CD1311008300000 DIODE 1311-008300000
D10 CD1311141480010 DIODE 1311-141480010
D11 CD1312031000000 SCHOTTKY
BARRIER DIODE
1312-031000000
D12 CD1312158190000 DIODE 1312-158190000
D15 CD1311001070050 DIODE 1311-001070050
D16 CD1311001040030 DIODE 1311-001040030 D
C1 CD1112337203380 E CAPACITOR 1112-337203380
C2 CD1112337203380 E CAPACITOR 1112-337203380
C3 CD1111472193001 C CAPACITOR 1111-472193001
C4 CD1111471082000 C CAPACITOR 1111-471082000
C5 CD1111471082000 C CAPACITOR 1111-471082000
C6 CD1131104084000 E CAPACITOR 1131-104084000
C7 CD1132476063060 E CAPACITOR 1132-476063060
C8 CD1132105083030 E CAPACITOR 1132-105083030
C9 CD1131103084000 E CAPACITOR 1131-103084000
C10 CD1132476063060 E CAPACITOR 1132-476063060
C11 CD1132105083030 E CAPACITOR 1132-105083030
C12 CD1111472193001 C CAPACITOR 1111-472193001
C13 CD1111472193001 C CAPACITOR 1111-472193001
C14 CD1132228073271 E CAPACITOR 1132-228073271
C15 CD1132228073271 E CAPACITOR 1132-228073271
C16 CD1132477073140 E CAPACITOR 1132-477073140
C17 CD1132477073140 E CAPACITOR 1132-477073140
C18 CD1131104084000 E CAPACITOR 1131-104084000
C19 CD1131104084000 E CAPACITOR 1131-104084000
C21 CD1112228063180 E CAPACITOR 1112-228063180
C22 CD1112228063180 E CAPACITOR 1112-228063180
C23 CD1132477053220 E CAPACITOR 1132-477053220
C24 CD1132107053060 E CAPACITOR 1132-107053060
C25 CD1131104084000 E CAPACITOR 1131-104084000 D
C26 CD1132106123160 E CAPACITOR 1132-106123160 D
C27 CD1132105083030 E CAPACITOR 1132-105083030
C28 CD1132106083710 E CAPACITOR 1132-106083710
C29 CD1116104132840 M.M.CAPACITOR 1116-104132840
C30 CD1118472212000 M.M.CAPACITOR 1118-472212000
C31 CD1132476063060 E CAPACITOR 1132-476063060 D
C32 CD1132107053060 E CAPACITOR 1132-107053060
C33 CD1132227073220 E CAPACITOR 1132-227073220
C34 CD1132227073220 E CAPACITOR 1132-227073220
R1 CD1237205012000 RESISTOR 1237-205012000
R2 CD1231103032000 RESISTOR 1231-103032000
R3 CD1231104082000 RESISTOR 1231-104082000
R4 CD1237005081000 RESISTOR 1237-005081000
R5 CD1237051082000 RESISTOR 1237-051082000
R7 CD1231470042000 RESISTOR 1231-470042000
R8 CD1231682042000 RESISTOR 1231-682042000
R9 CD1231103032000 RESISTOR 1231-103032000
R10 CD1231102042000 RESISTOR 1231-102042000
R11 CD1237205012000 RESISTOR 1237-205012000
R13 CD1231020022000 RESISTOR 1231-020022000
R14 CD1231020022000 RESISTOR 1231-020022000
R15 CD1231220042000 RESISTOR 1231-220042000
R16 CD1231332022000 RESISTOR 1231-332022000
R17 CD1231330082000 RESISTOR 1231-330082000
R18 CD1231330082000 RESISTOR 1231-330082000
R19 CD1231222082000 RESISTOR 1231-222082000
R20 CD1231222082000 RESISTOR 1231-222082000
R21 CD1231222042000 RESISTOR 1231-222042000
R22 CD1231223042000 RESISTOR 1231-223042000
R23 CD1231222042000 RESISTOR 1231-222042000
R25 CD1231123042000 RESISTOR 1231-123042000
R27 CD1231100042000 RESISTOR 1231-100042000
R28 CD1231102042000 RESISTOR 1231-102042000
R29 CD1231103032000 RESISTOR 1231-103032000
R31 CD1231103032000 RESISTOR 1231-103032000
R32 CD1231101042000 RESISTOR 1231-101042000
R33 CD1231102042000 RESISTOR 1231-102042000
R34 CD1231332022000 RESISTOR 1231-332022000
R35 CD1231682042000 RESISTOR 1231-682042000
R36 CD1231182062000 RESISTOR 1231-182062000
R37 CD1211225082000 RESISTOR 1211-225082000 D
R38 CD1231303062000 RESISTOR 1231-303062000 D
R39 CD1231682042000 RESISTOR 1231-682042000 D
R40 CD1231104042000 RESISTOR 1231-104042000 D
R41 CD1231472042000 RESISTOR 1231-472042000 D
R42 CD1231123042000 RESISTOR 1231-123042000 D
R43 CD1211100072000 RESISTOR 1211-100072000
R44 CD1231472042000 RESISTOR 1231-472042000
R45 CD1219241200051 VARISTOR 1219-241200051
R45 CD8031091000600 TUBE 8031-091000600
R46 CD1219241200051 VARISTOR 1219-241200051
R46 CD8031091000600 TUBE 8031-091000600
R47 CD1231103032000 RESISTOR 1231-103032000
R48 CD1237473082000 RESISTOR 1237-473082000
R49 CD1231220042000 RESISTOR 1231-220042000 D
R50 CD1231473042000 RESISTOR 1231-473042000
L1 CD1604102174000 COIL 1604-102174000
L2 CD1614100003010 INDUCTOR 1614-100003010
L3 CD1614100003010 INDUCTOR 1614-100003010
L4 CD1614100006000 POWER INDUCTOR 1614-100006000
L5 CD1614100006000 POWER INDUCTOR 1614-100006000
L6 CD2104000000280 COIL 2104-000000280
L7 CD1608300025000 TOROIDAL COIL 1608-300025000
L9 CD1608300025000 TOROIDAL COIL 1608-300025000
T1 CD2302409001000 TRANSFORMER 2302-409001000
T2 CD2302209001030 TRANSFORMER 2302-209001030
CN1 CD3101790221000 HEADER 3101-790221000
CN2 CD3101390421000 HEADER 3101-390421000
CN3 CD3101250621000 HEADER 3101-250621000
CX1 CD1111224133790 E CAPACITOR 1111-224133790
CX2 CD1111224133790 E CAPACITOR 1111-224133790
CY2 CD1111152143010 C CAPACITOR 1111-152143010
CY3 CD1111222143000 C CAPACITOR 1111-222143000
CY4 CD1111152143010 C CAPACITOR 1111-152143010
F1 CD2003400250430 FUSE 2003-400250430
LF1 CD2104000000280 COIL 2104-000000280
RL1 CD2501250050000 RELAY 2501-250050000 D
RT1 CD1214101000000 THERMISTOR PTC 1214-101000000
RT2 CD1214050003010 THERMISTOR NTC 1214-050003010
V1 CD1414116030000 TRANSISTOR 1414-116030000
V2 CD1412080500000 TRANSISTOR 1412-080500000
V3 CD1412080500000 TRANSISTOR 1412-080500000
V4 CD1412255510010 TRANSISTOR 1412-255510010
V5 CD1412080500000 TRANSISTOR 1412-080500000
V6 CD1411385500000 TRANSISTOR 1411-385500000 D
V7 CD1412080500000 TRANSISTOR 1412-080500000 D
VD1 CD1313001200010 Z DIODE 1313-001200010
VD2 CD1313000750010 Z DIODE 1313-000750010 D
VD3 CD1313001200010 Z DIODE 1313-001200010 D
VD4 CD1313055150000 Z DIODE 1313-055150000
Symbol No.
Part No. Part Name Description Local
