11
Rear panel
1 Telescopic antenna
2 AC IN (AC Input) jack
3 Battery compartment cover
4 SPEAKER terminals
Connect the provided speakers to these
terminals.
5 BEAT CUT switch (NORM 1, 2, 3)
Panel trasero
1 Antena telescópica
2 Jack AC IN (entrada de CA)
3 Cubierta del compartimiento de las pilas
4 Terminales de los altavoces (SPEAKER)
Conecte los altavoces suministrados a
estos terminales.
5 Conmutador de supresión de batidos (BEAT
CUT) (NORM 1, 2, 3)
Panneau arrière
1
Antenne télescopique
2
Prise d’entrée CA (AC IN)
3
Couvercle du compartiment des piles
4
Bornes de haut-parleurs (SPEAKER)
Raccorder les haut-parleurs fournis à ces
bornes.
5
Interrupteur de coupure de battement (BEAT
CUT) (NORM 1, 2, 3)
SEE BOTTOM
RIGHT LEFT
SPEAKER
7
1.5 x 8
8
1 2
6
354
123
NORM
BEAT
CUT
~
AC IN
1
2
3
45
