PD-42DX
1-2 (No.52088)
SPECIFICATION
Design and specifications subject to change without notice.
Item Contents
Dimensions (W x H x D) Plasma display unit 103.5cm x 64.0cm x 9.8cm (without Front speaker)
112.3cm x 64.0cm x 10cm (with Front speaker)
Receiver unit 43.5cm x 9.9cm x 38.2cm
Front speaker 4.2cm x 63.9cm x 5.4cm
Sub woofer 43.5cm x 23.0cm x 12.6cm
Mass Plasma display unit 33.0kg (without Front speaker)
35.5kg (with Front speaker)
Receiver unit 5.6kg
Front speaker 0.8kg (per one speaker without attachment bracket)
Sub woofer 3.7kg
TV RF System B, G, I, D, K, K1
Colour System PAL / SECAM / NTSC
• The external terminals also support the NTSC 3.58/4.43 MHz system.
Stereo System A2 (B/G, D/K), NICAM (B/G, I, D/K)
Teletext System FLOF (Fastext), TOP, WST (World Standard System)
Receiving Frequency VHF (VL) 46.25MHz ~ 168.25MHz
VHF (VH) 175.25MHz ~ 463.25MHz
UHF 471.25MHz ~ 855.25MHz
CATV Mid (X ~ Z+2, S1 ~ S10) / Super (S11 ~ S20) / Hyper (S21 ~ S41) bands
Intermediate Frequency VIF 38.9MHz (B / G, D / K, I)
SIF 33.4MHz (5.5MHz: B/G) / 32.9MHz (6.0MHz: I) / 32.4MHz (6.5MHz: D/K)
Colour Sub Carrier PAL 4.43MHz
SECAM 4.40625MHz / 4.25MHz
NTSC 3.58MHz / 4.43MHz
Power Input AC110V ~ AC240V, 50Hz / 60Hz
Power Consumption Plasma display unit Operate: 338W, Stand by: 0.5W
Receiver unit Operate: 35W, Stand by: 2.4W
Plasma Display Panel (PDP) QLE0020-001
42-inch wide aspect (16:9)
Screen Size Viewable area 105.7cm (measured diagonally) W: 92.1cm x H: 51.8cm
Display Pixels Horizontal: 1024 dots x Vertical: 768 dots [XGA]
Audio Output Front: 10W+10W, Sub woofer: 15W
Speaker Front speaker Direct Drive system 9.5cm x 1cm square x 2
Sub woofer (for bass sound) 16cm Round x 1
Aerial Input VHF/UHF 75 ohm Unbalanced coaxial
Input/
Output jack
VIDEO/
AUDIO IN
S-VIDEO
(VIDEO-2, 3, 5)
Mini-DIN 4 pin x 3
Y: 1V(p-p), Positive (Negative sync provided), 75 ohm
C: 0.286V(p-p) (Burst signal), 75 ohm
VIDEO-1
VIDEO-2
VIDEO-3 VIDEO 1V(p-p) Positive (Negative sync provided), 75 ohm RCA pin jack x 4
VIDEO-5 AUDIO 500mV(rms), High impedance RCA pin jack x 8
COMPONENT
VIDEO/
AUDIO IN
VIDEO-4
COMPONENT VIDEO RCA pin jack x 3
Y: 1V(p-p), Positive (Negative sync provided), 75 ohm
Pb/Pr: 0.7V(p-p), 75 ohm
• Progressive-scanning signals (625p or 525p) are available.
AUDIO 500mV (rms), High impedance RCA pin jack x 2
LINE OUT VIDEO 1V(p-p), Positive (Negative sync provided), 75 ohm RCA pin jack x 1
AUDIO 500mV(rms), Low impedance RCA pin jack x 2
AUDIO OUT (Fixed) 500mV(rms), Low impedance RCA pin jack x 2
Headphone 3.5mm Stereo mini jack x 1
Remote Control Unit RM-C63-1C
