(No.MB659<Rev.001>)1-3
RC-EZ51H
Design and specifications are subject to change without notice.
CD player CD capacity 1CD
Signal-to-noise ratio 60 dB
Dynamic range 60 dB
Tuner FM tuning range 88 MHz - 108 MHz
AM tuning range 530 kHz - 1 600 kHz
Antennas Telescopic antenna for FM
Ferrite core antenna for AM
Cassette deck Frequency response 100 Hz - 8 000 Hz
Wow & flutter 0.35% (WRMS)
Fast wind time Approx. 170 sec. (C-60 cassette)
General Speakers 10 cm cone x 2
Speaker impedance 4 Ω
Output power
2 W per channel min. RMS driven into 4
Ω
at 1 kHz with no more than 10% total harmonic distortions
Output terminals PHONES (3.5 Ø) x 1
Power supply AC 230 V , 50 Hz
DC 12 V (R20 (SUM-1)/D (13D)-size batteries x 8)
Power consumption 13 W (at operation)
1 W or less (on standby)
Dimensions 407 mm x 147 mm x 254 mm (W/H/D)
Mass Approx. 2.65 kg (without batteries)
