RX-E100RSL/RX-E100RSB
1-7
Prior to performing the following procedure, remove
the top cover and the front panel assembly.
Remove the two screws P attaching the power
switch board.
Remove the eight screws Q attaching the system
control board.
1.
2.
Removing the system control board /
power switch board (See Fig.14)
Fig.14
System control board
Power switch
board
Q
P
Q
Q
6
8
