SCHEMATIC DIAGRAMS
DX-U10A,DX-U10US,DX-U10UX
DX-U10UG,DX-U10UN,DX-U8US
DX-U8UX,DX-U8UG,DX-U8UN
DX-U6US,DX-U6UX,DX-U6UG
DX-U6UN
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-16 to 19
CD-ROM No.SML200706
COMPACT COMPONENT SYSTEM
No.MB616SCH
2007/6
COPYRIGHT 2007 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
SUPER VIDEO
SUPER VIDEO
CA-DXU6
SP-DXU6F SP-DXU6F
SP-DXU10W
CA-DXU8
SP-DXU10F
SP-DXU10F
SP-DXU10W
SP-DXU8S
SP-DXU8S
SP-DXU10C
CA-DXU10
SP-DXU10F SP-DXU10F
SP-DXU10W SP-DXU10W
SP-DXU10S SP-DXU10S
SP-DXU10C
