JVC SP-DXU10C User Manual

3-39
DVD loading board(Only DX-U6)
Block No. [1][0]
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW8 QSW0923-001 DETECT SWITCH
