JVC SP-MXJ206 Block Diagram

MX-J200/J206
3-13
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
Q
204 2SA1175TP-F TRANSISTOT GJ872910154
Q
205 2SD2144S/VW/-T TRANSISTOR GJ872992241
Q
301 KTC3199TPGR TRANSISTOR GJ312030111210
Q
302 KTC3199TPGR TRANSISTOR GJ312030111210
Q
303 2SA1175TP-F TRANSISTOT GJ872910154
Q
304 DTC114ESTP TRANSISTOR GJ872902967
Q
305 DTA114ES TRANSISTOR GJ872902921
Q
306 DTA114ES TRANSISTOR GJ872902921
Q
307 KTC3199TPGR TRANSISTOR GJ312030111210
Q
308 KTC3199TPGR TRANSISTOR GJ312030111210
Q
309 KTC3199TPGR TRANSISTOR GJ312030111210
Q
310 2SC945/QP/-T TRANSISTOR GJ872914245
Q
311 DTC114ESTP TRANSISTOR GJ872902967
Q
312 KTC3199TPGR TRANSISTOR GJ312030111210
Q
313 KTC3199TPGR TRANSISTOR GJ312030111210
Q
314 KTC3199TPGR TRANSISTOR GJ312030111210
Q
901 2SA943/R/ TRANSISTOR GJ872999343
Q
902 DTC114YSTP TRANSISTOR GJ872990437
Q
903 DTC114YSTP TRANSISTOR GJ872990437
Q
904 2SB1375 TRANSISTOR GJ872920960
Q
905 KTC3199TPGR TRANSISTOR GJ312030111210
Q
906 KTC3199TPGR TRANSISTOR GJ312030111210
Q
907 2SB1375 TRANSISTOR GJ872920960
Q
908 2SA1175TP-F TRANSISTOT GJ872910154
Q
909 DTA114TS TRANSISTOR GJ872990435
Q
910 DTC114TSTP TRANSISTOR GJ872990440
Q
911 KTC3199TPGR TRANSISTOR GJ312030111210
Q
912 DTC114YSTP TRANSISTOR GJ872990437
Q
913 2SA1175TP-F TRANSISTOT GJ872910154
Q
914 KTC3199TPGR TRANSISTOR GJ312030111210
Q
915 2SB1375 TRANSISTOR GJ872920960
Q
916 KTC3199TPGR TRANSISTOR GJ312030111210
R 1 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 2 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 11 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 12 GJ250084742103 CARBON RESISTOR 1/6W J 470K
R 13 GJ250085602103 CARBON RESISTOR 1/6W J 56
R 14 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 15 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 16 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 17 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R 18 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 19 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 21 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 22 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 23 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 24 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 25 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 26 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 27 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 51 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 52 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 53 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 54 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 55 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 56 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 57 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 58 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 59 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 60 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 61 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 62 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 63 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 64 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 65 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 67 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 68 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 69 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 70 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 71 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 72 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 101 GJ250083932103 CARBON RESISTOR 1/6W J 39K
R 102 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 106 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 107 GJ250082732103 CARBON RESISTOR 1/6W J 27K
R 108 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 109 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 110 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R 111 GJ250081222103 CARBON RESISTOR 1/6W J 1.2K
R 112 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 113 GJ250081242103 CARBON RESISTOR 1/6W J 120K
R 114 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 115 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 116 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 117 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 118 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 119 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 120 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R 121 GJ250086812103 CARBON RESISTOR 1/6W J 680
R 122 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 123 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R 124 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R 125 GJ252561081708 RESISTOR
A
2W K 0.1
R 126 GJ252561081708 RESISTOR
A
2W K 0.1
R 127 GJ255051512601 FUSE RESISTOR
A
150 OHM 1/4W 5%
R 128 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 129 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 130 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 131 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 132 GJ124782191 CARBON RESISTOR 390 1/4W 5%
R 133 GJ124782191 CARBON RESISTOR 390 1/4W 5%
R 134 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 136 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 137 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 138 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 139 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 140 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 141 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 142 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 150 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 151 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 181 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 201 GJ250083932103 CARBON RESISTOR 1/6W J 39K
R 202 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 206 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 207 GJ250082732103 CARBON RESISTOR 1/6W J 27K
R 208 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 209 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 210 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R 211 GJ250081222103 CARBON RESISTOR 1/6W J 1.2K
R 212 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 213 GJ250081242103 CARBON RESISTOR 1/6W J 120K
R 214 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 215 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 216 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 217 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
(Main board)
