JVC SP-MXJ206 Block Diagram

MX-J200/J206
3-14
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
R 218 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 219 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 220 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R 221 GJ250086812103 CARBON RESISTOR 1/6W J 680
R 222 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 223 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R 224 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R 225 GJ252561081708 RESISTOR
A
2W K 0.1
R 226 GJ252561081708 RESISTOR
A
2W K 0.1
R 227 GJ255051512601 FUSE RESISTOR
A
150 OHM 1/4W 5%
R 228 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 229 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 230 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 231 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 232 GJ124782191 CARBON RESISTOR 390 1/4W 5%
R 233 GJ124782191 CARBON RESISTOR 390 1/4W 5%
R 234 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 236 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 237 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 238 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 239 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 240 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 241 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 242 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 250 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 251 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 281 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 301 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 302 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 303 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 304 GJ250084702103 CARBON RESISTOR 1/6W J 47
R 305 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 306 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 307 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 308 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 309 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 310 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 311 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 312 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 313 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 314 GJ250084742103 CARBON RESISTOR 1/6W J 470K
R 315 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 316 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 321 GJ250081002103 CARBON RESISTOR 1/6W J 10
R 322 GJ250081502103 CARBON RESISTOR 1/6W J 15
R 323 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 324 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 325 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 326 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 327 GJ250081512103 CARBON RESISTOR 1/6W J 150
R 328 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 329 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 330 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 331 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 332 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 333 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 334 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 335 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 336 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 337 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 338 GJ250081812103 CARBON RESISTOR 1/6W J 180
R 339 GJ250081532103 CARBON RESISTOR 1/6W J 15K
R 340 GJ250083302103 CARBON RESISTOR 1/6W J 33
R 341 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 342 GJ250088212103 CARBON RESISTOR 1/6W J 820
R 343 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 344 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 901 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 902 GJ255051012601 FUSE RESISTOR
A
100 OHM 1/4W 5%
R 903 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 904 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 905 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 906 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 907 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 908 GJ255052292601 FUSE RESISTOR
A
1/4W J 2.2
R 909 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 910 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 911 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 912 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 913 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 914 GJ250081092103 CARBON RESISTOR 1/6W J 1
R 915 GJ250081092103 CARBON RESISTOR 1/6W J 1
R 916 GJ250081092103 CARBON RESISTOR 1/6W J 1
R 917 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 918 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 928 GJ250083302103 CARBON RESISTOR 1/6W J 33
R 929 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 930 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 931 GJ250081022103 CARBON RESISTOR 1/6W J 1K
RY301 GJ151592111 RELAY
T 2 GJ123388511 IFT
X 1 VCX5044-001 X'TAL
(Main board)
