MX-J200/J206
3-15
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
Item
Parts number Parts name Area
Remarks
A
C 701 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 702 GJ112689891 E.CAPACITOR 220MF 20% 10V
C 704 GJ112691651 E.CAPACITOR 1000MF 20% 6.3V
C 705 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 706 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 707 GJ116221321 A.CAPACITOR 50V SL J 39PF
C 708 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 709 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 710 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 711 GJ116220721 A.CAPACITOR 50V SL J 22PF
C 712 GJ116220721 A.CAPACITOR 50V SL J 22PF
C 713 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 714 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 715 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 716 GJ270114760310 E.CAPACITOR 10V M 47UF
C 717 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 718 GJ270192260310 E.CAPACITOR 50V M 22UF
C 719 GJ270192260310 E.CAPACITOR 50V M 22UF
C 723 GJ270191050310 E.CAPACITOR 50V M 1UF
CN701 GJ340021130108 CONNECTOR 13PIN WHT
CN702 GJ340021130108 CONNECTOR 13PIN WHT
CN704 GJ340021160108 CONNECTOR 16PIN WHT
CN706 GJ169537131 CONNECTOR 10PIN WHT
CN708 GJ340072030102 CONNECTOR 3PINS
D 701 1SS133T-77 DIODE GJ871999133
D 702 1SS133T-77 DIODE GJ871999133
D 703 1SS133T-77 DIODE GJ871999133
D 704 1SS133T-77 DIODE GJ871999133
FL701 BJ753GN FL DISPLAY GJ373020031110
FW701 GJ353130280110 CABLE 13PINS
FW702 GJ353130230107 CABLE 13PINS
FW703 GJ353100200110 CABLE 10PINS
IC701 MN101C35DYA IC GJ313010661223
IC702 GP1U291Q IC GJ313010661005
L 701 GJ141033031 INDUCTOR 22UH 10%
L 702 GJ141050931 INDUCTOR 10UH 5%
L 703 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 707 GJ141050931 INDUCTOR 10UH 5%
Q
701 KTC3199TPGR TRANSISTOR GJ312030111210
Q
702 KTC3199TPGR TRANSISTOR GJ312030111210
Q
703 KTC3199TPGR TRANSISTOR GJ312030111210
Q
704 2SC2668/O/-T TRANSISTOR GJ312020351201
Q
705 2SC2668/O/-T TRANSISTOR GJ312020351201
Q
706 2SA1175/F/ TRANSISTOR GJ872910154
Q
707 DTA114ES TRANSISTOR GJ872902921
Q
708 DTA114ES TRANSISTOR GJ872902921
Q
709 DTA114ES TRANSISTOR GJ872902921
Q
710 DTA114ES TRANSISTOR GJ872902921
Q
711 DTA114ES TRANSISTOR GJ872902921
Q
713 DTC114YSTP TRANSISTOR GJ872990437
Q
714 DTC114YSTP TRANSISTOR GJ872990437
Q
715 DTC114YSTP TRANSISTOR GJ872990437
R 70 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 701 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 703 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 704 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 705 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 706 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 707 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 708 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 709 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 712 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 713 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 714 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 715 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 717 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 720 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 721 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 722 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 723 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 724 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 725 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 726 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 727 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 728 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 729 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 730 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 731 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 732 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 733 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 735 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 736 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 737 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 738 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 739 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 740 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 741 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 742 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 743 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 744 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 745 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 746 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 747 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 748 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 749 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 750 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 751 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 752 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 753 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 754 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 755 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 756 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 757 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 758 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 761 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 762 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 763 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 764 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 769 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 770 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 771 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 772 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 773 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 774 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 775 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 776 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 778 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 779 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 780 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 781 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 782 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 783 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 784 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 785 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 786 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 787 GJ250081032103 CARBON RESISTOR 1/6W J 10K
(Display board)
