MX-J200/J206
3-16
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
R 788 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 789 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 790 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 791 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 792 GJ250083312103 CARBON RESISTOR 1/6W J 330
RA701 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA702 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA703 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA704 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA705 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA706 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA707 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA708 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA709 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA710 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA711 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA712 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA713 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA714 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA715 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA716 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA717 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA718 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA719 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA720 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA721 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA722 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA723 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA724 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA725 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA726 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA727 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA728 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA729 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R1037 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R1038 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R1039 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R1040 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R1041 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R1042 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R1043 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R1044 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1045 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1046 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1047 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R1049 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1050 GJ250081032103 CARBON RESISTOR 1/6W J 10K
X 701 GJ178159811 RESONATOR CSA8.00MTZ 200
X 702 GJ361000230009 CRYSTAL 32.768KHZ
(Display board)
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
CN101 GJ169537131 CONNECTOR 10PIN WHT
LED12 GJ374301022103 LED SLR-342MCT32
LED13 GJ374301022103 LED SLR-342MCT32
LED14 GJ374301022103 LED SLR-342MCT32
LED15 GJ374301022103 LED SLR-342MCT32
R1001 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1002 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1003 GJ250088212103 CARBON RESISTOR 1/6W J 820
R1007 GJ250083312103 CARBON RESISTOR 1/6W J 330
R1008 GJ250083312103 CARBON RESISTOR 1/6W J 330
R1009 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1017 GJ250083312103 CARBON RESISTOR 1/6W J 330
R1018 GJ250083312103 CARBON RESISTOR 1/6W J 330
R1019 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1020 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1021 GJ250088212103 CARBON RESISTOR 1/6W J 820
R1022 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R1023 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R1024 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R1025 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R1026 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R1027 GJ250081232103 CARBON RESISTOR 1/6W J 12K
R1028 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1029 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1030 GJ250088212103 CARBON RESISTOR 1/6W J 820
R1031 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R1032 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R1033 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R1034 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R1035 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R1036 GJ250081232103 CARBON RESISTOR 1/6W J 12K
S1003 GJ390110181120 TACT SWITCH TAPE
S1004 GJ390110181120 TACT SWITCH AUX
S1005 GJ390110181120 TACT SWITCH BAND
S1006 GJ390110181120 TACT SWITCH CD
S1013 GJ390110181120 TACT SWITCH STOP
S1014 GJ390110181120 TACT SWITCH TUN+
S1015 GJ390110181120 TACT SWITCH TUN-
S1016 GJ390110181120 TACT SWITCH REPEAT
S1017 GJ390110181120 TACT SWITCH RANDOM
S1018 GJ390110181120 TACT SWITCH PROGRAM
S1019 GJ390110181120 TACT SWITCH S.MODE
S1020 GJ390110181120 TACT SWITCH CANCEL
S1021 GJ390110181120 TACT SWITCH SET
S1022 GJ390110181120 TACT SWITCH TIM/CLK
S1023 GJ390110181120 TACT SWITCH REC
S1024 GJ390110181120 TACT SWITCH DUBBING
S1025 GJ390110181120 TACT SWITCH CD REC
S1026 GJ390110181120 TACT SWITCH REV MODE
S1027 GJ390110181120 TACT SWITCH PRESET-
S1028 GJ390110181120 TACT SWITCH PRESET+
S1029 GJ390110181120 TACT SWITCH DECK A/B
S1030 GJ390110181120 TACT SWITCH DISPLAY
S1031 GJ390110181120 TACT SWITCH A.BASS
(Multi-control board)
