MX-J200/J206
3-17
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 04
A
LED11 GJ374301012101 LED
R1006 GJ250086812103 CARBON RESISTOR 1/6W J 680
S1001 GJ390110181120 TACT SWITCH POWER
W1002 GJ353030140107 CABLE FLAT 3PINS
(Power switch board)
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 05
A
R1010 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1011 GJ250088212103 CARBON RESISTOR 1/6W J 820
R1012 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R1013 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R1014 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R1015 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
S1007 GJ390110181120 TACT SWITCH CD1
S1008 GJ390110181120 TACT SWITCH CD2
S1009 GJ390110181120 TACT SWITCH CD3
S1010 GJ390110181120 TACT SWITCH EJE1
S1011 GJ390110181120 TACT SWITCH EJE2
S1012 GJ390110181120 TACT SWITCH EJE3
W1004 GJ353020120107 CABLE FLAT 2PINS
(Eject switch board)
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 06
A
C1001 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C1002 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
SW101 GJ299000570003 VR ENCODER
W1005 GJ353030080107 FLAT CABLE 3PINS
(Volume board)
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 07
A
C1051 GJ116229421 A.CAPACITOR 50V B K 1000PF
C1052 GJ116229421 A.CAPACITOR 50V B K 1000PF
J1053 GJ342010160111 PHONE JACK
L1051 GJ141033231 INDUCTOR 47UH 10%
L1052 GJ141033231 INDUCTOR 47UH 10%
L1053 GJ141039721 F.BEAD INDUCTOR 1.1UH
W1051 GJ353040350107 FLAT CABLE 4PINS
(H.phone jack board)
