Outdoor FM antenna
(not supplied)
Disconnect the supplied FM antenna, and connect
to an outdoor FM antenna using a 75 Ω wire with
coaxial type connector (IEC or DIN45325).
FM antenna (supplied)
AM loop antenna (supplied)
Turn it until the best reception
is obtained.
To connect the FM antenna (supplied)
Extend it so that you can obtain the best reception.
For better FM reception
To connect the AM loop antenna (supplied)
To assemble the AM loop antenna
To connect the speaker cords
Press and hold
InsertRelease
Red
Black
From left
speaker
From right
speaker
