JVC SP-UXJ50 Service Manual

UX-J50
1-6 (No.22032)
SECTION 2
Disassembly method
2.1 Main body
2.1.1 Removing the metal cover
(See Fig.1~3)
(1) Remove the six screws A on the back of the main body.
(2) Remove the two screws B on each side and remove the
metal cover in the direction of the arrow.
Fig.1
Fig.2
Fig.3
Metal cove
r
A
A
A
B
B

JVC SP-UXJ50 Specifications

General

Brand	JVC
Model	SP-UXJ50
Category	Stereo System
Language	English
